PRODUCT REVIEWS
Coil punching and shearing solution
Pivatic Oy designs , manufactures and markets punching , cutting and bending equipment and lines for the thin sheet-metal manufacturing industry . The Finnish specialist tailors its lines to produce parts for OEMs in various industry sectors from metal furniture ; white goods and electrical enclosures to HVAC equipment and industrial construction . The lines include automated punch and bend from coil or blank stock production systems for highvolume producers of precision sheet-metal components .
Founded in 1975 , with production facilities and headquarters in Hyvinkää , Finland , it has a wide sales and partner network around the globe of more than 30 representatives . The customisation of hundreds of lines installed worldwide has been a key pillar of Pivatic ’ s success . It is a member of The Ursviken Group , a global provider of high-end solutions for sheet-metal manufacturers which provides a worldwide business network for production , sales and services .
Pivatic is now offering a new coil punching and shearing solution to metal manufacturers .
“ Pivatic systems give users multiple options
to run your parts . Using advanced nesting , operators may choose the part type , amount and the order in which they want the parts to be produced . All parts of the same material can be produced from the same coil width , nested side-by-side . After the Pivatic double punching process , material is cut to length ( CTL ) from the coil by a shear ,” it explained .
To nest parts side-by-side on a strip , Pivatic uses a CTW ( Cut-to-Width ) station to shear and separate the nested parts . All parts are stacked or buffered automatically in piles on top of pallets for easy transportation or transferred directly to follow-up processes .
Waste is minimised ( in the X and Y axes ) by filling the coil with nested parts . By separating each process step , it aims to deliver significant leaps in productivity .
See the QR code ( right ) for video of the new coil punching and shearing process .
Pivatic will be running an Open House in Finland on 31 October 2023 and 1 November 2023 . Register at https :// pivatic . com / en / news / You can also meet Pivatic at the FABTECH exhibition in Chicago , USA ( 11-14 September 2023 ), on stand A2937 and at Blechexpo 2023 in Stuttgart , Germany ( 7-10 November 2023 ), on stand 1111 in Hall 1 . n
www . pivatic . com
On the surface
Fladder Danmark offers a wide range of manual , automatic and special machines for processing thin and thick sheet metal parts . These are used for deburring ; oxide / dross removal ; surface finishing ; denibbing and intermediate sanding .
The Fladder ® 300 / GYRO HYBRID system for grinding , deburring and edge rounding removes laser spatter and burrs from material after laser cutting and punching . Edges are rounded in the same pass . The machine has a modular structure with a grinding belt and the oscillating FLADDER ® Gear head . Workpieces are transported through the two grinding processes on a vacuum belt .
“ To achieve optimal cycle times for the two very different grinding processes and to avoid unwanted heating of the workpiece , calibration grinding is carried out using a cross grinding belt . The grinding belt is pressed towards the workpiece by an
The Fladder ® 300 / GYRO HYBRID system . oscillating contact wheel . The short contact time protects against impermissible heating and ensures optimal utilisation of the abrasive belt . Flexible FLADDER ® Abrasive Cylinders are used to create perfect rounding and radius on the edges as the last step in the process ,” explained Fladder . n
www . fladder . com
