FOCUS ON TOOLING
Teamwork in action .
Tooling for Jaguar car engine parts .
INVEST FOR
Progression press tooling .
SUCCESS
Paragon Toolmaking in the UK has over five decades of experience in press tool manufacture , from concept and prototype through to design and manufacture .
“ Over the last two years , the company has invested significantly in its workforce and machinery and has won acclaim for its dedication to training and apprenticeship schemes .”
Paragon Toolmaking in the UK provides complete tooling solutions for a wide range of sectors and its customers range from SMEs to major national and international organisations . Established by Carl Canty in 1969 , parts manufactured with its tools are used by OEMs such as Rolls Royce ; Land- Rover ; Siemens ; Aston Martin ; Ideal Boilers ; BMW ; Lotus and Swift Caravans . Clients come from sectors including automotive ; construction ; aerospace ; pharmaceuticals and white goods .
Based in Kingston upon Hull in the UK , it boasts over five decades of experience in press tool manufacture ( from concept and prototype through to design and manufacture ). Many of its employees have been trained inhouse through its apprenticeship scheme and stayed with the company , some now for over twenty years , “ with a combined experience of more than 250 years .”
“ Our try-out facilities enable us to handle
We can trial , develop and prove all press tools thoroughly before delivery to our customers ’ production sites
and manufacture projects from the most intricate to simple and largest to smallest . We manufacture bespoke items , jigs , machinery and equipment of up to 10 tonnes in weight , serving all industries . We also offer new and innovative press tool design solutions , as well as advanced 3D modelling and formability analysis . As well as our design and engineering expertise , we provide efficient CNC manufacture for high-quality parts and inspection / testing to meet customer specifications ,” it told ISMR .
The toolmaking process
Examples of the tooling produced by the company include progression press tools ; transfer tools ; jigs and fixtures tools ; stage tools ; forming tools ; blanking tools and deepdraw tools . It also offers a tool repair service . Using in-house try-out presses , it can build and trial tools of up to 400 tonnes with a maximum die set size of 2.75m x 1.5m . It also utilises a Stanko 160-ton press with a bed size of 1.25 x 1.7m .
Paragon Toolmaking aims to speed up product development with early prototypes .
“ Our relationship with customers often begins at the concept stage of a new product and as we have more than 50 years ’ experience , we can add huge value from the very first stage . By working alongside our customers , and using low-cost temporary tooling , we can produce ‘ Metal ’ prototype
100 | ismr . net | ISMR September 2023
