FOCUS ON FOLDERS
“ Shaft-controlled bending is assured through fully electro-kinetically driven bending joints for quiet and powerful operation. Inclined bending beams and optimised clamping beam geometry offer a high degree of flexibility and short counter-folds,” added Biegemaster.
The Biegemaster Dura long folder offers a wide range of applications for bending of roof, wall and façade. Common profiles range from 3-15 metre bending lengths. It is optionally equipped with a hydraulic adjustable clamping beam for material thickness adjustment. There is an archive of all previously used projects on the machines and an intuitive control system via multi-touch display with a wide range of functions.
“ The freely positionable foot switch enables both hands to remain free when fixing the sheet metal,” said the manufacturer.
“ For double bends, the Biegemaster XBend bends material thicknesses of up to 2mm steel sheet metal automatically( lengths of 3-12 metres. Fully automatic bending is possible in two directions without turning the sheet around and an electronic back gauge ensures precise positioning. The clamping beam can be controlled with millimetre precision for perfect folds and automatic loading assistance is featured for the easy insertion of sheet metal. It also features an automatic gripper system and side infeed,” added the manufacturer.
The S-BEND is the company’ s folding solution for heavy-gauge materials and demanding profiles. Featuring a hydraulic system and automatic crowning, it offers bending capacity for up to 3mm steel and 4mm aluminium
The BMS multi-touch control system enables intuitive operation by touching the screen. New profiles can be created quickly or created using touchscreen painting. The control system can draw on stored profiles. Automatic bend sequence calculations with graphic simulation and illustration are also offered.
At EuroBLECH 2026 in Germany, the manufacturer will be demonstrating its fully automatic double bender on its stand.
Blech-Tec GmbH manufactures mini bending machines for small parts production. This includes bending machines for technical springs and contacts that other machines can no longer bend or that otherwise require special tools( from small bending parts with 0.05mm to 3mm spring steel or 5mm busbars and more).
Its BT-500 is a combination folding, press brake and pressing machine for small parts. Combining the bending processes offers flexibility, as the processes have their geometric advantages. It is a compact freestanding machine, which can be operated while sitting or standing. The design allows different kinds of bending, even in one program. The BT-500 is specially designed for bending small parts.
“ Our patented folding process yields a result with hardly any bending traces because the tool always lies flat against the workpiece. In addition, users benefit from the precision of the BT-500, which is designed for small parts, and the comfortable two-finger guide unit. The unique design enables different kinds of bending, even in one program. The comfortable two-finger guide supports these new possibilities,” said the manufacturer.
The BT-150 2.0 is designed as a table machine for even smaller parts.
The BT-500 combi folder for bending small parts.
Companies in The Bradbury Group have been manufacturing roll forming machinery since 1959. The Group has also developed a hydraulic folder, which features the Intelli- Fold™ Controller made by its partners at Beck Automation. The Intelli-Fold™ Controller features resident programs and a graphic display that allows operators to save time by sketching a part profile and then entering
More than 200mm of folding beam retraction provides significantly greater horizontal bending clearance in the Thalmann D-POWER double folder, while reinforced clamping beams add stability.
Folded metal on the Mario Die & Fixture bender.
its dimensions and angles. Screen prompts guide the process.
Bradbury Folders come with free firmware downloads from Beck Automation and controllers with optional office-to-folder download capability. Standard models are designed to handle 30-gauge to 11-gauge metal and are available in five lengths— 13’, 21’, 26’, 33’ and 40’.
The Marion Die & Fixture bender is designed to form 90-degree flanges on drainage tubing end sections while maintaining the integrity of the material throughout the bending process. It accommodates flange lengths of 12-48 inches and flange heights of 3-6 inches.
CIDAN Machinery Group offers a comprehensive machine portfolio from manual segment folding machines and modular machine solutions to systems for fully automated sheet metal profile production. The Group was founded in 1907 and has four well-known brands: CIDAN( metal folders and metal shears) from Sweden, Forstner( coil lines), nuIT( software) from Austria and Thalmann( long folding machines) from Switzerland.
The Group will present a selection of innovative machines, controls and software solutions at EuroBLECH in Hanover, Germany, this October. It will launch the new D-POWER double folder from Thalmann at EuroBLECH in Hanover from 20-23 October 2026.
