FOCUS ON FOLDERS
with 300 ° of clearance. Its portfolio includes the D-series double folder.
“ With SmartBend, our machine performs minimal, simultaneous movements for each bend, that previously required large, sweeping motions. Thanks to a range of different bending paths and movement patterns, profiles can now be produced fully automatically, which were once either manually processed or considered impossible to bend,” it said.
“ The EVOBEND S-Series is a single bending machine with innovations such as retractable loading tables and automated grippers, as standard. Its unique design without swivelling bending beams allows operators to work closer to the machine. This not only boosts efficiency but also enhances comfort and safety,” it continued.
Forge in Mattoon, Illinois( USA) has the North American patent rights to European folding manufacturer Variobend’ s products and is the U. S. manufacturer of Variobend equipment. Its portfolio includes single / double folders, a double bender and a single bender. It builds Variobend machines in the U. S. with SAE hydraulic lines, hoses and other components. In fact, all hydraulic components are sourced in the USA. See also Variobend entry in this article.
Gabella Macchine is an Italian manufacturer of sheet-metalworking machines with 60 years of experience in the production of cut-to-length lines, slitting lines, multi-blanking lines, press brakes and folders.
GMC Machine Tools’ electromechanical sheet metal folders have been designed to bend light-duty sheet metal. They are equipped with an Italian ESA 6-axis CNC controller and an 11” touch-screen monitor. Most of its product line is manufactured in Taiwan. Other machines are designed in the U. S. and manufactured in Italy and China.
H. M. Transtech, s. r. o. is a privately owned Slovakian company with more than 25 years of experience in the production of sheetmetalworking machines. Its production programme offers standard machines as well as machines with modern graphic CNC control systems. The production range includes manual folders up to a maximum length of 4.5m; shears; plate bending machines; motorised and hydraulic shears;
The MAXI Plus folder from H. M. Transtech. motorised folding machines; coil-processing / sheet lines and other special machines.
“ Our motorised folders are suitable for small-batch and mass production of simple open and closed profiles and boxed products. Motorised sheet metal folding machines are highly flexible in the transition to a different type of products. The capacity of the motorised folding machines ranges from 1-8mm of thickness while length is in the range of 1-5m. A wide selection of accessories, including motorised and manual rear bumpers as well as control options from manual to advanced CNC graphic control, are available,” said the company.
Jorns AG is a Swiss, family-run business and internationally active specialist manufacturer of semi-automatic and fully automatic bending machines / folders. The company also offers accessories( e. g. cutting tables, shears and support arms) as well as bending software / control, service and support. Jorns AG celebrated its 50-year milestone anniversary in 2023.
At Blechexpo 2025 in Stuttgart this October, Jorns will be exhibiting with manufacturers Gebr. Spiegel AG and SPÓŁKA STO-LARCZYK, as well as with its local sales and service partner( Maschinen Stockert), using the motto“ Together we are STRONG.”
“ This joint presentation at Blechexpo will benefit our customers because we can show them a‘ total package’ as a solution over just a few square metres on the booth. A Jorns JDB-150G-HM-DP-SE-1250-JC100-6.4-dsp double bending machine will be displayed, equipped with a 1250 automated side-infeed system as well as with the JC100 control that offers a direct interface to the Bendex Enterprise Suite from MicroSea,” Jorns confirmed
“ Our specialty is manufacturing bending machines and double bending machines as well as accessories for processing sheetmetal. We have been developing and building these since 1973,” commented the folding specialist.
After celebrating 150 years of trading in 2022, UK-based Morgan Rushworth offers a
The Jorns JDB double bending machine.
range of manual, hydraulic and CNC folders. Its HBP hydraulic box and pan folder uses an adjustable manual angle-setting device. Clamping and bending is controlled by a joystick or foot pedal or combination of the two, allowing easy positioning of the material for folding. It also offers a manual BPC Box and Pan. Powered and hydraulic section benders also feature in its portfolio.
Morgan Rushworth ESR CNC folder.
Its EXR range of CNC folders are manufactured with a rotating upper beam with one straight rail and one set of high divided tools that can both be utilised in the same folding program without any manual tool change. The back gauge is integral to the rear support table, which is suitable for the folding of large sheets as the weight of the material is supported, resulting in a traditionally two-operator job being able to be performed with just one. Three models are available( bending up to 2.5mm mild steel).
The ESR range of CNC folders are designed to produce fast, accurate and consistent folded parts. Available from 1.5m to 4.2m bending lengths, all models are supplied with a 1m powered back gauge, with optional longer back gauges( including U- and L-shaped configurations). All ESR models are supplied with a straight rail with optional high divided tools for box and panel-type operations( bending up to 5mm mild steel).
“ Our EXL range of CNC folding machines are manufactured with a rotating upper beam with one straight rail and one set of high divided tools that can both be utilised in the same folding program without any manual tool change. This versatile design
94 | ismr. net | ISMR October 2025
