AutoForm-DieDesignerPlus
AutoForm Engineering GmbH , a supplier of software solutions for stamping and BiW assembly processes , is introducing its newly developed software , AutoForm- DieDesignerPlus . With this software , users can create and compensate high-quality CAD surfaces within the AutoForm Forming suite . The integration of AutoForm-DieDesignerPlus within the AutoForm software environment ensures data continuity during process design .
“ The creation and compensation of highquality CAD surfaces as preparation for manufacturing has typically been carried out using external CAD software . This software requires user familiarity with its application and the tedious multiple importing and exporting of data from and to CAE software as well as the creation and potential integration of additional external documentation ,” explained AutoForm .
“ However , AutoForm-DieDesignerPlus provides a set of geometry creation features within the easy-to-use AutoForm user interface . With this software , users can quickly create final die-face geometry without requiring additional CAD software . This new option is tailored to the needs of engineers responsible for final CAD-quality surfaces and eliminates the need to import and export data , resulting in a higher level of efficiency and ensuring data continuity ,” it continued .
“ AutoForm- DieDesignerPlus is best applied during the process design phase to facilitate the creation of high-quality CAD surfaces . These surfaces are required for the final validation simulations and compensation of die surfaces , which will be exported afterwards for use in die manufacturing . A new level of efficiency in the process design phase is achieved because of the seamless data flow and the use of process plan information created earlier ( in the concept development stage ),” added Dr . Markus Thomma , CMO of the AutoForm Group .
With AutoForm-DieDesignerPlus , he summarised , users can create high-quality CAD surfaces for manufacturing within the AutoForm software environment . This software , with its new features and capabilities , is designed to ensure the seamless flow of data and facilitate daily work in process design departments .
AutoForm offers software solutions for sheet-metal forming and BiW assembly process . With over 400 employees dedicated to this field , it is a leading provider of software for product manufacturability , tool and material cost calculation , die-face design and virtual stamping as well as BiW assembly process optimisation .
Besides its headquarters in Switzerland , AutoForm has offices in Germany ; The Netherlands ; France ; Spain ; Italy ; Czech Republic ; Sweden ; USA ; Mexico ; Brazil ; India ; China ; Japan and Korea . It is also present through its agents in more than ten other countries . n
www
. autoform . com
TIG welding powerhouse
EWM offers TIG welders a compact , powerful inverter welding machine , the new Picotig 220 puls DC . Weighing in at just ten kilograms , the welding machine has a robust , lightweight design making it suitable for workshops and construction sites .
“ Lightweight and easily portable for maximum efficiency , we have expanded the Picotig series with a new model : the Picotig 220 puls DC . The integrated Power Factor Correction ( PFC ) ensures an increased power output while the machine ’ s high efficiency and standby function help to save both power and costs . Users can achieve welding currents of 220 A with 40 % duty cycle for TIG welding and currents of 190 A
The Picotig 220 puls DC can be used with conventional and digital EWM multi-functional welding torches with display and remote-control functions . with 35 % duty cycle for MMA welding . This is a significant increase in performance in comparison to the previous model ,” explained EWM .
The welding technology manufacturer has made the welding machines in its Picotig series more convenient to operate . With a mains lead measuring 3.5m , the Picotig 220 puls DC offers a wide working radius with no need for an extension cable . The sturdy carrying handle also comes with a cable holder for the mains cable and built-in storage compartment for wear parts . The robust casing provides protection for all the connections on the rear side . A protective cap on the front side protects the controls against damage and dirt .
“ The Comfort 3.0 mini control allows users to select all pulse , standard and innovative welding processes , or users can set tack points with precision using the spotArc ® and spotmatic functions . The Picotig 220 puls DC is also suitable for MMA welding and is compatible with cellulose electrodes . The control is extremely easy to operate , supporting users with even the
The new Picotig 220 puls DC from EWM weighs just ten kilograms .
most complex of welding tasks . Users now have multiple options when choosing a welding torch , as the Picotig 220 puls DC can be used with both conventional and digital EWM multi-functional welding torches with display and remote-control functions ,” highlighted EWM .
The five-pole torch connection is also compatible with EWM X technology . Whether it ’ s the TIG Retox XQ welding torch , spotArc ® welding torch or a welding torch used with the previous Picotig 200 puls DC model , the user is free to choose and can adapt the welding equipment to suit the task at hand . A wide range of accessories is also available . n
