Waterjet cutting for jet engine turbines
When fabricating jet engine turbines , wire EDM is often used since the technology provides narrow cuts for precise and complex shapes . However , wire EDM is also a timeconsuming manufacturing process ( set-up time and processing ). It is also a thermal manufacturing process which influences the properties of the material . However , new and innovative waterjet cutting technology is now being proposed for this aerospace application .
“ Fabricating turbines for jet engines is a time-consuming process that requires precision . Since wire EDM is recognized as a quite slow machining technology , an international jet-engine supplier explored the possibility of reducing the manufacturing time of fixed turbine parts by replacing wire EDM with other processing technologies . The challenge was to find a technology that could meet the tough requirements ,” explained Water Jet Sweden ( WJS ).
“ Thermal cutting technologes , such as laser and fibre laser , were tested but there was too much heat impact on the material , so laser cutting had to be rejected . The next step was to investigate waterjet technology as an option . The drop-shaped contours of the jet turbine required five-axis machining and , at the same time , a very narrow cut to handle small
FiveX Ultra with micro cutting head for advanced waterjet cutting .
contours , sharp corners and small tolerances , with a fine cutting surface ,” it added .
Traditional waterjet cutting was difficult to apply , but the challenge was met by the new FiveX Ultra waterjet cutting system from Water Jet Sweden . FiveX Ultra is a full 3D cutting machine ( 0-120˚ cutting ) designed to manage precision cutting assignments . As the FiveX Ultra can be equipped with a FAWJ Micro Cutting Tool , it also provides extremely fine cuts for precise and complex shapes .
Following a customer visit to the Water Jet Sweden Demo Centre in Ronneby ( Sweden ), the development of a new manufacturing routine for jet engine turbines started .
Waterjet cutting is a cold cutting process , with no heat-affected zones , and the cutting surface is “ satin smooth ” according to
WJS . With the narrow cutting beam of the micro cutting tool , it cuts sufficiently sharp corners but adjustments needed to be made to the slightly cone-shaped cutting beam ( a characteristic of waterjet cutting ). The TVL ( tapered angle control , variable speed and delay compensation ) function was fine-tuned to eventually provide an approved cutting profile .
“ The fact that it was not possible to make direct measurements of the parts was a challenge in the work process . Instead , interpreters are used to check the contour accuracy . In small steps , the process was gradually optimised to finally obtain the correct and precise profile . We have now developed a process to optimise cutting parameters for turbine production , using a unique combination of our new 3D waterjet cutting machine and our FAWJ micro cutting tool ,” explained Tony Ryd , Co-Founder and CTO , Water Jet Sweden .
Time savings were made over several stages of the manufacturing process . Cutting times were improved , set-up time could be reduced to a minimum ( with fixtures instead of time-consuming wiring ) and a new auto calibration tool significantly reduced the time from loading to production . n
