PRODUCT REVIEWS numerous innovations , including a revamped 3D component import , extended features ( such as the ability to copy nesting plans ) and improved work ergonomics through Dark Mode ,” it continued .
Modular material handling solutions can be configured to customer requirements .
Bevel cutting with BEVEL-U
“ Rapidly increasing laser power , different bevel shapes , new cutting gases ; innovative solutions are needed to ensure that lasercutting machines can meet today ’ s demands for productivity and dynamics . We responded to these developments with the innovative ELEMENT L laser cutting machine . The centrepiece of the machine is the Bevel-U bevel unit , which was specially developed for the laser process ,” added the manufacturer .
Messer ’ s ELEMENT L laser machine combines uniform piercing and faster cuts in laser precision cutting . It cuts mild steel , stainless steel and aluminium in working widths of between 1,600mm and 5,100mm and a working length of up to 25,000mm with O₂ and N₂ as well as an optional automatic gas mixing unit . A central component of the machine concept is the Bevel-U bevelling unit .
The Bevel-U enables bevel angles of between -50 ° and + 50 ° as well as different edge shapes ( I , V , Y , X , K ) on the workpiece for a subsequent welding process . The bevel angle is infinitely adjustable during the laser cutting process . Magnetic collision protection for the cutting head is as much a part of the design of the bevelling unit as a manual control panel for all drives so that adjustments can be made directly on the machine .
“ Even with material thicknesses of 50mm , Bevel-U can produce precise and repeatable bevelled parts with a wide variety of bevel contours in the highest cutting quality thanks
The new ICSORT system can automate sorting tasks .
The Bevel-U bevel unit .
to its unique design , a major advantage in edge preparation for automated robot welding . An automatic testing and calibration routine ensures consistently high quality , even after a nozzle change . Combined with the automatic nozzle changer Laser Nozzle Control ( LNC ), productivity can reach a new level thanks to fully automatic management of the cutting nozzles ,” outlined the cutting specialist .
Automated material handling
With its ICSORT system , Messer Cutting Systems also presented a material handling solution for sheet metal processing at this year ’ s EuroBLECH . In combination with Messer ’ s cutting systems and own software , ICSORT creates an efficient production environment . During the live demonstration of ICSORT at the trade fair stand , trade visitors were able to see the integrated software and hardware solutions in practice .
“ The ICSORT system automates all loading , unloading and sorting tasks . This allows the user to maximise machine utilisation . Due to its modular design , the system can be customised to individual customer requirements . It is suitable for precisely positioning large raw materials on the cutting table and for sorting small cut parts quickly and efficiently . This is made possible by 40 individually controllable magnets which can be flexibly adapted to all mild steel moulds and ensure the safe movement of parts ,” explained the manufacturer .
“ With two bridges and the powerful magnet units , ICSORT can handle even large components ( regardless of their dimensions or material thickness ). The specially developed OmniFab software package also allows work processes to be optimised and controlled from the workstation ,” it concluded . n
www . messer-cutting . com
