“ Thanks to this innovative process and partnership with Intrinsic , customers can now automatically sort parts that could not be removed using conventional solutions , even with a batch size of one ,” outlined Schneider . These include small or complex parts that are prone to tipping over or tilting in the scrap skeleton . However , even thicker parts can be separated out and automatically sorted by the sorting process .
The two sorting modules can also be retrofitted at a later date which , said TRUMPF , reduces the initial investment and allows the degree of automation to be increased step by step .
New laser cutting machine
TRUMPF also launched a new laser cutting machine at EuroBLECH which , it said , is particularly suitable for users with smaller production volumes who are looking for a machine with low investment and operating costs . The TruLaser Series 1000 Lean Edition offers the same quality standard as TRUMPF ’ s high-end models but , said the company , is significantly more affordable .
For the new TruLaser Series 1000 Lean Edition , TRUMPF has adapted the range of functions of its TruLaser Series 1000 . The machine does without various functions that are primarily relevant for users with high throughput .
“ When companies have a low production volume , it is often not worthwhile to have their own sheet metal processing unit , because they cannot utilise conventional machines to full capacity . With the new TruLaser Series 1000 Lean Edition , these kinds of users will be able to produce the parts they need themselves in the future . This provides flexibility and independence ,” explained TRUMPF product manager , Patrick Schüle , adding that , with this machine , users get the same access to TRUMPF ’ s customer service .
The TruLaser Series 1000 Lean Edition retains the universal cutting unit with reversible collision protection . If the cutting unit collides with a component that has been cut free , it deflects and the operator can then push it back into the holder by hand .
“ To prevent collisions from happening in the first place , the TruLaser Series 1000 Lean Edition also features the nanojoint technology we developed in which components are fixed with the smallest of holding points and are , therefore , particularly easy to remove after cutting ,” added TRUMPF , highlighting the machine ’ s ease of operation and an online monitoring function for the cutting unit .
At EuroBLECH 2024 , TRUMPF also highlighted its improved machine diagnostics to increase productivity and lower service costs as well as its new TRUMPF TruLaser Series 3000 Bevel Cut Edition . This automatically prepares components for welding and can produce bevelled cutting edges ( chamfers ) on the top and bottom edge of the component while cutting , saving an otherwise necessary downstream work step ( see the October issue of ISMR ).
TRUMPF won a EuroBLECH 2024 award for bevel cutting on its 2D laser cutting machines , confirmed during the exhibition . n
www
. trumpf . com
Surface finishing for small parts
At the EuroBLECH trade fair in Hanover this October , Q-Fin ’ s F250 for finishing small sheet metal parts was awarded the prestigious EuroBLECH award in the ‘ Surface Technology ’ category ,
“ The F250 , the successor to our F200 , translates the advanced technology of our larger machines into a compact and versatile format especially designed for deburring , edge rounding and finishing small metal parts . This compact powerhouse impressed the jury and
The F250 . the public with its high level of automation and ease of use ,” Q-Fin told ISMR .
“ With a belt width of 250mm and a maximum product height of 100mm , the F250 offers extensive possibilities for deburring , edge rounding and finishing small sheet metal parts . Each processing station is softwarecontrolled , giving users complete control . The innovative vacuum system ensures that even the smallest parts , starting from 20 x 20mm , stay securely in place . The alternative magnet system allows safe processing of products as small as 10 x 10mm . A fixed table height and a movable inner frame add to the stability and make it easy to integrate the F250 into automation solutions ,” it added .
Using Qonnect + software , the F250 can be connected to ERP systems for extensive process monitoring . The automatic height adjustment of the grinding belt optimises the process by preventing scratches on products when this station is idle . The electronic brush compensation extends the machine ’ s lifespan by ensuring that brushes do not brush into the belt . A 10-inch HMI touchscreen provides intuitive and clear operation . n
The new TruLaser Series 1000 Lean Edition features a user interface that is designed to make it easy to operate . https :// qfin-deburring . com
