FOCUS ON TUBE FORMING
Parmigiani Macchine ’ s pipe and section bending machine .
Tube and pipe processing
Parmigiani Macchine SAS has a universal pipe and section bending machine with CNC control in its portfolio .
Prada Nargesa SL , from Spain , has over 50 years of experience in manufacturing industrial machinery . Its new generation CC60 and CC90 CNC non-mandrel tube and pipe benders , featuring touch-screen control , can bend up to 180 º curves on hollow profiles . Materials can be round , oval , square , rectangular and made of a range of different metals such as steel , aluminium , stainless steel , copper etc .
Its new MC650 Nargesa section and pipe bending machine is designed to carry out mass production through the control , which saves the position of the rollers in each curve to repeat the same operations later without longitudinal positioning control . It is suitable for manufacturing flanges , greenhouses , railings and large structures for construction and has a maximum capacity for bending round pipe of 4 ” inches or 101.6mm .
Preco ’ s RT1000 is designed for precision laser cutting small diameter tubes for medical devices such as surgical instruments , stents and other implantable devices . It incorporates
The Tubeformer from Spiro International SA .
Tube display at Wire & Tube , Duesseldorf , Germany .
a granite base , precision servo drives , rigid work holding , fibre-delivered laser sources and Preco ’ s fine cutting head .
PLATINO ® is the general purpose 2D laser cutting machine by Prima Power which cuts a broad range of materials and thicknesses . Change-over to tube processing can be achieved with zero set-up time , said the Italian manufacturer . It is available in two sizes ( 1530 and 2040 ), and with laser powers ranging from 2500W to 5000W .
Platino Fiber Evo is now available with high brilliance , energy-efficient fibre lasers with 2- , 3- , 4- or 6kW power . The new fibre laser cutting head with adaptive collimator , designed and manufactured by Prima Power , is equipped with a single focus lens .
3D laser cutting machines from Prima Power include the Laser Next 2141 and Rapido multipurpose machines . Laser Next 1530 and Laser Next 2130 models are suitable solutions for massive or specialised automotive production . Its LASERDYNE multi-axis laser processing systems can also be used for 3D cutting , welding and drilling . SAY-MAK MAKINE IMALAT VE DIS TIC . LTD . STI . in Turkey offers sheet-metal working machines ; direct-gear motorised guillotines ; hydraulic and motorised plate bending machines ; hydraulic and motorised section and pipe bending machines ; hydraulic workshop presses ; hand-lever guillotines ; manual folding machines and more .
SigmaTEK Systems is a global provider of end-to-end CAD / CAM software solutions .
“ Our product suite covers the full range of fabrication workflow ; from quoting to shipping , including robust integration with a wide range of business systems and the ability to program all major laser , waterjet , oxyfuel , plasma , punch , router , knife , press brake and tube machines ,” it said .
Swiss manufacturer Spiro International SA produces air duct systems for the HVAC and sheet metal industry .
“ As the inventor of the spiral duct machine , the Tubeformer , we have built a sound reputation in the HVAC and sheet metal industry over the last six decades ,” it told ISMR .
SVR Ltd . manufactures ventilation and chimney machines as well as systems for metal laser welding and the cutting of blanks and tubes based on fibre sources ( specifically developed for the requirements of HVAC and metal shop manufacturing ).
Swagelok offers a variety of tube benders such as electric benders with electronic control for automated bending of tubing with outside diameters ranging from one to two inches and 25-50mm . Bench top benders are also supplied for bending of tubing with outside diameters ranging from 1 / 4 to 1 1 / 4 inches and 6-30mm . Hand tube benders that are portable and feature roll dies that reduce bending force and tube ovality , for bending tubing with outside diameters 1 / 8 , 1 / 4 , 5 / 16 , 3 / 8 and 1 / 2 inches , and 3- , 6- , 8- , 10- and 12mm , are also supplied .
ISMR May 2023 | ismr . net | 53
