FOCUS ON FILTRATION
A PROTECTIVE SHIELD
Designing
and integrating an effective dust collection system for thermal cutting operations is not a one-size-fits-all exercise for manufacturers.
“ Considering the filtration challenges posed by thermal cutting applications, supporting effective dust collection for laser and plasma cutting applications is essential for manufacturers.”
By
Nicolas Van der veken, Product Manager, Donaldson.
Plasma and laser cutting are core processes of flexible metal fabrication. However, these thermal cutting applications generate considerable levels of fume and particulate, including extremely fine particles, which can present a variety of operational challenges and be detrimental to cutting machinery. As particles can range from sub-micron to dozens of microns in size, controlling them requires a properly selected and installed filtration system that transforms the entire cutting work envelope into an effective fume-capture system.
System designs depend upon the cutting environment and process parameters. For example, a large plasma table has different airflow requirements compared to a small laser table. Plasma cutting also produces different particle-size ranges than lasercutting. Even related functions, such as automated material loading systems, affect system designs because of increased cutting time. These considerations must therefore be factored into design requirements just as much as material type and thickness, cutting kerf widths and part nesting.
Hazard analysis
As with any process, a hazard analysis should be performed before selecting a dust collection strategy. It is important to understand dust characteristics and the materials being collected as these may impact important design decisions. For example, mitigating ignition sources is one aspect of an overall combustible dust strategy. Sparks are typically present in any thermal cutting process, and there are many passive and active methods to mitigate them.
Other strategies for reducing the risk of a combustible dust event may include reviewing the material that is collected or installing the dust collection system outdoors. If filtered air is returned to the production environment, additional equipment may be needed to indicate that an event is occurring or reduce damage to nearby equipment. Decisions like these should be reviewed as part of a hazard analysis.
Hood and dust collector size
Effective dust collection requires hoods that can efficiently capture and control particulates. However, simply buying the most expensive dust collector and installing high-efficiency filters will not increase overall efficiency if the hood captures only half the dust and fume. Hood location and design should therefore be reviewed to continuously pull consistent air volumes and capture contaminants.
The size of a dust collector is dependent upon the airflow that is required to capture and contain the fume and particulate. The dust load and collection system’ s workload should also be taken into account. Normally, the wider the cutting table, the greater the airflow required to contain the dust, resulting in a larger dust collection system. Other variables can also influence airflow, including the material being cut, the size of the table, the fraction of the table that is covered by the workpiece and the number of open zones in a table during the cutting process.
Although the airflow needed to capture the fume from a laser cutting and plasma cutting process may be identical, dust collector sizes may differ because of the different dust loads and material characteristics. This is because the volume and physical shape of the dust will impact how the material builds up on the media; this is known as the dust cake. Smaller dust particles on the filter tend to cake together, with smaller void spaces between particles, which in turn increases the pressure needed to pull air through the layer of dust. If this is not taken into account, a dust collection system may consume more energy and require more frequent cleaning.
Automation factors
Laser cutting holes in sheet metal.
If the automation of laser and plasma cutting is increased, this will also impact collector sizing considerations. In manual cutting, operators take parts off a table and then load new sheets. During this downtime, a dust collector can“ catch up” on pulse cleaning under heavy load conditions.
Modern collection systems use on-demand cleaning to help extend the operational life of filter media. Compared to continuous cleaning of filter media, pulsing filters only function when they are needed which allows systems to run continuously while reducing filter fatigue and extending filter life.
46 | ismr. net | ISMR December 2025 / January 2026
