FOCUS ON PUNCHING
PACKING A PUNCH
We outline the benefits, techniques, machinery and features of sheet metal punching operations for manufacturers. The technique works well for repetitive patterns and high-volume production, supporting a variety of materials and thicknesses.
“ Sheet metal punching is often used in the production of ventilation panels, control boxes, brackets, enclosures and decorative panels.”
Image: Shutterstock. com.
Perforated, punched aluminium.
Image: LVD.
Sheet metal punching.
Sheet metal punching, used to create holes, slots, cut-outs and intricate shapes in metal sheets with speed and precision, is a vital process in modern fabrication. Using a programmed punch and die, this technique works very well for repetitive patterns and high-volume production. The method is particularly effective for parts such as enclosures, panels and brackets, where speed and accuracy are essential.
The process is often an essential stage in broader fabrication projects. It is often used in the production of ventilation panels, control boxes, brackets, enclosures and decorative panels. The technique works well for repetitive patterns and high-volume production, supporting a variety of materials and thicknesses. Common punching techniques include piercing( making a hole in sheet metal without taking any material away), notching( removing a small fragment of material from the edge of sheet metal) and slotting( creating a long, thin groove in sheet metal).
CNC punching can also combine multiple punches in a single process, allowing for intricate designs and high repeatability. Punching is widely used in functional and decorative applications across numerous industries, offering the flexibility to handle a wide range of designs and materials.
Automotive, aerospace, construction and electronics are just some of the industry sectors that utilise modern punching processes. Sheet metal punching strikes a strong balance of speed, precision and costeffectiveness, particularly for manufacturers who process high part volumes.
Intelligent functions and various removal and sorting options on the punching machines assist operators as they work, making processes more fluid and safer. Options also include loading, unloading, disposal and toolhandling in custom-fit automation variants.
Features and applications
Useful features in sheet metal that can be created by punching include louvres for air vents, dimples for locating positions, bridges for slide rails or back stops. The rapid hit rate of the process makes it suitable for creating perforated parts, such as grilles. The use of cluster tools means that manufacturers can punch many holes in a grid at the same time, drastically reducing run times. This can be used very effectively for parts such as ventilation grilles or LED panels.
Advanced control software and lean nesting techniques also save material usage, contribute to sustainability and increase the overall efficiency of punching operations.
“ However, CNC punching is at its most economical when producing simple shapes in larger volumes. For example, apertures such as holes, squares and obrounds as well as more sophisticated shapes like countersinks, louvres, dimples and locking tabs. With custom tooling, we can even incorporate folds thereby creating an entire part. Cluster tools, on the other hand, can be used to punch large grid patterns, creating multiple holes and slots in a single punch stroke,” commented UK sheetmetal specialist, Alroys. The step-by-step punching process includes:
■ Positioning the metal sheet between the punch and die.
■ Applying downward force to cut the metal.
■ Removing the scrap material or keeping the punched piece, depending upon the design.
■ Shaping or perforating the metal according to the required specifications.
