2019 International Conference on Artificial Intelligence and Advanced Manufacturing (AIAM) FPGA-based Moving object Detection with Interferences Lih-Jen Kau, Member ,IEEE, Guo-Ting Jhao, Wei-Xiang Lai, and You-Ran Liu Department of Electronic Engineering, National Taipei University of Technology No.1, Sec. 3, Chung-Hsiao E. Rd., Taipei 10608, Taiwan Email: [email protected], [email protected], [email protected], [email protected] we will see in the experiment that the proposed system is very useful and can have a throughput as high as 54.4MPixels/sec. Abstract— Visual interferences caused by bad weather condi- tions can have a negative impact on the performance of a visual surveillance system. How can we detect the moving object in a quickly and accurately manner is a very important step for further analysis, e.g., object recognition, object tracking, event detection, or behavior analysis, in a visual surveillance system. However most of the moving object object detection systems are based on a high-level micro-processor for its highly complex algorithm. Moreover, the detection accuracy is often affected by the environment of the system used. In this paper, we proposes using an FPGA (Field Programmable Gate Array) to realize a visual surveillance system so that the real-time requirement can be achieved. Besides, the proposed system can adapted itself to a variety of environmental situations, especially for the condition of light changes, such as the existence of a shadow, raindrop, etc. As we will see in the experiment that a very good performance in terms of power consumption, memory usage, throughput, as well as the capability of adapt to interference can be achieved in the proposed system. II. P ROPOSED P IPELINE A RCHITECTURE The proposed system is a fourteen-stage pipeline architec- ture as shown in Fig. 1. The details of individual stage will be explained in this section. • Stage 1. CCD Capture: This stage is to capture the video frame via CMOS sensor. • Stage 2. Raw data to RGB color space: In this stage we convert the CMOS raw data to RGB color model. • Stage 3. Color quantization: To ſt the SDRAM memory as well as the width of the data bus. The RGB resolution will be quantized, where the quantized R, G, and B components will be 5, 6, and 5 bits in width, respectively. • Stage 4. SDRAM storage: Therefore, this stage is to store four video frames to the four SDRAM memory banks in ALTERA DE2-70 module. • Stage 5. Multi-interference removal: The multi interference removal algorithms can be divided into two parts: the part for “ambient brightness change detection” and “reconstruction”. We ſrst examine if R n , G n , and B n are all greater than a predeſned threshold T 1 . If so, the pixel is regarded as high brightness pixel (e.g., caused by the light reƀection due to the rain drop), and we will try to recover the pixel value with (1). ⎧ |R n − R n−1 | > T 2 ⎪ ⎪ ⎪ ⎪ P , if |G ⎪ n−1 n − G n−1 | > T 2 ⎪ ⎪ ⎪ |B ⎪ n − B n−1 | > T 2 ⎪ ⎪ ⎪ ⎨ |R n − R n−2 | > T 2 (1) P n = ⎪ ⎪ P , if |G ⎪ n−2 n − G n−2 | > T 2 ⎪ ⎪ ⎪ |B n − B n−2 | > T 2 ⎪ ⎪ ⎪ ⎪ ⎪ ⎪ ⎩ P n , otherwise. Index Terms— FPGA, Pipeline, Moving object detection, Multi- interference, Rain drop removal I. I NTRODUCTION Harsh environments tend to degrade the performance of a visual surveillance system. In general, harsh environments can be classiſed into two categories; (i)stable type: fog and haze (ii)dynamic type: rain, hail, and snow. Among which, the impact of the dynamic rain drop is the most common situation in various weather conditions. Besides, most of the aforementioned interference will result in changes in ambient brightness and cause performance degradation of the mov- ing object detection system. For this, many researches have been proposed to solve the effect of an instant light change, e.g., the shadow and light reƀection, in a visual surveillance system [1][2],[6]-[8]. In this paper, we propose an FPGA- based moving object detection system, which can adapt to the environment interference caused by light intensity change due to the existence of a shadow and the rain drops. We ſrst try to ſnd and recover the value of those pixels affected by the increasing of light intensity, e.g., the light reƀection due to the rain drops. Secondly, a series of video processing techniques including shadow detection will be applied to remove the salt and pepper noise and decide the area affected by shadow. Thirdly, the time sequence subtraction on consecutive video frames will be used to ſnd the contour of moving objects. After that, we apply the morphology operation. Finally, we perform segmentation for those detected moving objects. As 978-1-7281-4691-1/19/$31.00 ©2019 IEEE DOI 10.1109/AIAM48774.2019.00043 where the T 2 in (1) is a predeſned threshold. That is we try to recover the value of those pixels affected by the raindrop with three consecutive video frames. 181
