International Core Journal of Engineering 2020-26 | Page 183

the authenticity of the certificate. If the verification succeeds,
the local certificate is sent to the gateway. After the identity
verification of both parties is completed, the VPN encrypted
tunnel can be established.
Fig12. Test the round-trip latency of 100 ICMP packets
VI. C ONCLUSION
The rapid development of the IoT technology has brought
profound changes to the society. More and more terminal
intelligent devices are connected to the network. If the
security of the IoT system cannot be effectively guaranteed,
the deployment and application of the IoT technology cannot
achieve significant development. IoT gateway is the key link
of the interaction between the perception layer and the
application layer, which plays an important role in ensuring
the security of the IoT system. Based on previous studies,
this paper proposes a data transmission protection scheme
combining PUF technology and IPSec VPN using China
cryptographic algorithm, and carries out specific
implementation and deployment tests. The results show that
the gateway is convenient to deploy and flexible to configure,
which can effectively improve the network security on the
basis of meeting the general communication requirements
and transmission rate of the IoT system.
Fig9. Gateway certifies Server certificate
Fig10. The server verifies the user certificate at the gateway
C. Performance Test and Results
Testing of gateway performance is primarily a test of
latency, throughput, and stability. Start iperf in the terminal
of the IoT server, and then log in to the gateway system. In
the terminal tool of the gateway system, enter: iperf -c
192.168.32.1 -i 2 -t 30, -c to start in client mode. The test
results show that under the VPN tunnel, the TCP throughput
reaches an average of 95 Mbits/s.
A CKNOWLEDGMENT
This research was financially supported by the National
Key Research and Development Plan (2018YFB1004101),
Key Lab of Information Network Security, Ministry of
Public Security (C19614), Special fund on education and
teaching reform of Besti (jy201805), the Fundamental
Research Funds for the Central Universities(328201804,
328201910), key laboratory of network assessment
technology of Institute of Information Engineering, Chinese
Academy of Sciences.
R EFERENCES
[1]
[2]
[3]
Fig11. Test TCP throughput results after establishing a VPN tunnel
[4]
After establishing a secure tunnel connection, log into the
home gateway system and use ping command to test the
delay of VPN server Intranet host PC1 (192.168.32.100).
Through testing 100 ICMP packets: ping 192.168.32.100-c
100, as shown in the figure, in the VPN tunnel established by
this gateway, the average round-trip delay is 4.145ms, the
shortest is 2.860ms, and the longest is 4.680ms. Send 100
packets with a loss rate of 0.
[5]
[6]
[7]
[8]
[9]
161
Frustaci M, Pace P, Aloi G, et al. Evaluating critical security issues of
the loT world; Present and Future challenges[J]- IEE Internet of
Things Joumal, 2017, PP(99):1-L.
Siegel J E, Kumar S, Sarma S E. The Future Internet of Things:
Secure, Eficient, and Model- Based[J]. IEEE Internet of Things
Journal, 2017.
SUN Chuang,WANG Ying-guan,LI Zhen-wei. Network fusion model
based on wireless sensor network and mobile communication
networks[J]. Modern Electronics Technique,2013,36 (07):4-7+10.
YE Gaoyang,BI Ran. Design and implementation of smart home
system based on Internet of things[J].Journal of Computer
Applications, 2014,(S1):318-319. +351.
Xin Hailiang,Zhong Peisi,Zhu Shaoqi,Yu Yingjing.Research of smart
home furnishing control system by Internet of Things based on
ZigBee[J].Measurement Control Technology and Instruments, 2013,
39( 12):79-81.
FENG Jianfeng.Design of Smart Home System Based on ARM and
ZigBee Technology[D].Jilin University, 2014.
WANG Lei,HE Yong,ZHANG Yu,KONG Weitian.Design and
application of portable voice system based on smart
home[J].Computer Engineering and Design,2018,39(05):1290-1295.
XU Zhexin,ZHANG Yilin,LIN Xiao,WU Yi. Design of Smart Home
Router Based on OpenWrt and ZigBee[J]. Computer Engineering,
2017, 43(03):94-98+104.
Becker G T. On the pitfalls of using arbiter- PUFs as building
