SLOPE STABILITY MONITORING
picking up tiny falling rocks at great distances
long before the human eye can see them.
RockSpot is the industry’s first end-to-end
solution able to trigger alerts on rockfalls and
other collapse events, filling the gap in critical
monitoring. Each single rockfall event is detected
in real time and customizable alerts issued to
geotechnicians and working crews. Users can
access RockSpot data from the innovative
GeoCloud platform, a web-based application
giving you immediate access to all important
data relative to the events, georeferenced and
overlaid on site map.”
RIEGL’s broad portfolio of mining
solutions
For mining applications, RIEGL offers a broad
portfolio of high-end Waveform-LiDAR sensors
and systems, especially 3D Terrestrial Laser
Scanning Systems “for extremely fast acquisition
of highly accurate scan data in long-range
applications,” says Thomas Gaisecker, Manager
of the Mining Business Division.
RIEGL VZ-2000i, the latest state of the art 3D
terrestrial laser scanning system operates with
RIEGL LiDAR Waveform Technology provides
“highly accurate data with extensive coverage up
to 2.5 km range in combination with extremely
high measurement rates of up to 1.2 million
measurements per second.” The established
RIEGL VZ-4000 and RIEGL VZ-6000 offering
solutions for niche application with demand for
extreme long-range capabilities (up to 6,000 m).
“Besides the outstanding range performance
RIEGL LiDAR Waveform Technology enables
multiple target capability and precise results
even in harsh conditions like rainy, dusty and
foggy environments.” This enables also
penetrating of safety-wires and high accurate
data on the surface behind.
RIEGL hardware supports smart operation by
remote scanner control, onboard software apps,
and customisable workflows. “Connectivity by
LAN, Wi-Fi, and 3G/4G interfaces enables the
integration of RIEGL sensors into any given
environment. With all these options the system is
designed and developed for the next generation
of mine planning – the fully remote-operated
digital mine.”
RIEGL says it sensors can be remotely
operated from anywhere by utilising the
mentioned connectivity interfaces and the RIEGL
VZ-i Series Scanner Control App available for
Windows, Android and IOS platforms. The
onboard software apps and customisable
workflows guarantee autonomous data-
processing und cloud-upload of the results.
These fully automatically just in time produced
scan-data results can be used for a variety of
different mine-applications essential for the
Left: Automatic slope failure detection; Right: Radial dam deformation
caused by water pressure
ROCKSPOT
Filling the gap in critical monitoring
!o1h"ro| bv-mbmmo-ঞ;u-7-u
vv|;l-0Ѵ;|oѴo1-|;ķ|u-1h-m7
-Ѵ;u|omuo1h=-ѴѴvbmu;-Ѵঞl;
RockSpot never sleeps and monitors night and day.
)b|_ - Ѵom]Ŋummbm] ;m;u] voѴঞomķ v;uv 1-m
depend on 24/7 coverage
@;1ঞ; uo1h=-ѴѴ _--u7 lbঞ]-ঞom v|u-|;]b;v
possible to protect mine workers and assets
