Main oil pump #1 Main oil pump #2 Hydraulic cylinders Oil tank Hydraulic concept of pulsation free DHT controlled air vessel. These alternatives operate in a similar way to the pulsation dampener and although they have some other advantages/disadvantages they will not be further described in this paper. Pulsation free DHC (VZ system) The most effective way of dealing with the phenomenon of pressure pulsations is to avoid generating them. This is done by creating a discharge flow that is continuous despite the reciprocating motion of the pistons. With a two cylinder pump this can be achieved if both pistons are driven independently of each other. Using this concept, the pump is divided into two single-cylinder pumps each driven by its own hydraulic system. The individual systems are controlled by a PLC that controls the respective piston speed profiles so that the total net discharge flow is constant, resulting in a constant discharge pressure. The speed profile of the individual pistons can only be controlled if their respective positions and speeds are monitored continuously during the complete length of the stroke. This is achieved with a linear transducer system that is integrated in the hydraulic side of each cylinder. The timing of the piston speeds and the corresponding opening and closing of the valves is critical for the correct functioning of the system. As described above, the VZ system requires both the cylinders to be driven independently from each other; each cylinder is driven by its own Paste cylinders dedicated oil pump. Note that depending on the total required power, the two main oil pumps can be driven by the same electric motor. The VZ system with its pre-compression of the paste in combination with the timed takeover of the discharge stroke only works on a piston pump with hydraulically actuated valves. In regards to a swing tube pump pre- compression is not possible. Pulsation free DHT In the case of a traditional swing tube pump, there is no pre-compression of the suction cylinder because the swing tube is not connected to the suction cylinder. Therefore, the flow compensation of the pump has to be done differently. Furthermore, the power drawn from the main HPU motors is also subject to these fluctuations. This can result in a higher motor power and motor control centre (MCC) rating, increasing the system investment costs. Possibly, the (existing) power supply system cannot handle these electrical power demand fluctuations. A third cylinder has to be introduced to compensate for the flow variation during the switch-over. However, rather than allowing the cylinder to discharge a certain volume into the main pipeline over a predetermined time period, with limited beneficial results, the following unique working principle has been applied: during each discharge stroke of one of the main cylinders, an additional flow above the nominal slurry flow is delivered. This additional flow is fed into an additional third Min 100% 0 2 4 8 6 time(s) P12 International Mining | MARCH 2018 Supplement 10 12 0% 14 Max cylinder 1 cylinder 2 cylinder 3 power consumption Schematic concept of pulsation free DHT cylinder. The hydraulic flow from this third cylinder is transferred back to a hydraulic pump, and mounted on the same motor shaft as the main hydraulic pumps. The additional energy required to move the third cylinder is thus fed back to the same motor shaft, apart from minor power losses resulting from piston friction and efficiency losses. During switch- over, the third cylinder discharges into the main pipeline allowing the pump to operate at nominal flow. The third cylinder starts to ramp up when the discharge cylinder is ramping down to generate a smooth take over from one cylinder to another. Due to the constant flow, pressure fluctuations in the pump discharge line will be reduced to a minimum. As a result of the energy recovery of the third cylinder during its fill stroke, fluctuations in HPU power consumption are minimised to the level of friction and efficiency of the hydraulics for the third cylinder. A slurry non- return valve is installed in the slurry line downstream of the pump to prevent back flow from the main pipeline and the third cylinder to the pump. For a recent project a pulsation free DHT pump was built and commissioned. The pump design flow is 200 m 3 /h against a design pressure of 120 bar. The pulsation free DHT concept allowed the system to have the full pressure available for continuous pumping and required no excess pressure capacity for acceleration losses. It was understood that for the same project this could be estimated as being 50-100% of the average operating pressure in case traditional DHT technology would be used. The pulsation free DHT technology has many benefits including: n reduced power requirements in the range of 25%, allowing for additional operational design margins n smaller sized PD pumps and related investments costs in the range of 10-15% n reduced costs for pipeline and pipeline supports in the range of 10-15% Conclusion While with DHC hydraulic valve style pumps a constant flow/pulsation free option has been available for years, the same fully integrated concept is now also available for DHT pumps. Through the introduction of a third cylinder, combined with energy recovery, this concept can now be applied for DHT swing tube pumps. Pressure pulsations are minimised, power requirements are reduced by 25% and investment costs in the PD pump system by 10%. The concept is patent pending and offers a unique solution to customers in the mining industry. *The full Pulsation free DHT white paper will be presented at Paste 2018
