Pressure relief tee step by step operation
The operation of the pressure relief tee is shown in the attached sequence:
1
Both nuts are undone
3
Joints shown as
Victaulic, other joint
types available
Smooth
consistent
internal
bore
Fully welded
construction
Nut is retained
by shoulder
5
2
Plug part is
semi-captive
Tool pass through slot
Simple removal of
polycarbonate
windows by single
bolt
Conclusion
Although there is a place in a paste pipeline for
automated valves and cleanout tees it is proposed
that this device fits a specialty niche between
those two extremes and offers a superior pressure
relief capability than cleanout tees or blasting
tees, while doing so at a much lower cost than an
automated valve. We believe that these devices
should be installed at approximately every 300 m
spacing in a paste backfill line to ensure that a
safe and reliable depressurisation option is
available throughout the pipeline.
Smooth
consistent
internal
bore
Patented
design
Tool reversed
Tool used to knock
coupling from shoulder
6
4
Lift end
of bar
7
Tool used as a lever
to pull plug down
Figure 1. Operation of the Pressure Relief Tee
