UNDERGROUND LOAD & HAUL
to take full advantage of the new features in the system. Switching operating modes – from automation to smart assisted teleoperation and vice versa – is simply done by pressing a button.“
AutoMine ® Lite provides extra productive hours each day by allowing the continued operation of the loader or truck during blast clearance times. Additionally, equipment utilization is increased as operators can hand over between shifts much faster without the need to locate and travel to the equipment. Another advantage of AutoMine ® Lite is that it significantly extends the lifetime of equipment, available later this year. The new LHD represents as the machine runs optimally, reducing wear the next generation of Cat LHDs as it replaces its and tear and maintenance costs. The AutoMine ® G Series predecessor. The R1700 features system is designed to a high level of safety and multiple engine configurations, a new ergonomic eliminates operator exposure to potential operator cabin, greater payload, a compact hazards in underground environments. profile, efficient power train and extended
With the new AutoMine ® Lite 2.0, Sandvik durability to deliver low cost-per-tonne truck continues to drive the evolution of underground loading and load-haul-dump production. equipment automation. The solution is built on The new R1700 handles a payload of 15 t, 20 % the proven AutoMine ® platform and can also be more than the R1700G and supporting efficient easily expanded to AutoMine ® Multi-Lite, which three-pass loading of the 45 t capacity Cat enables each system operator to simultaneously AD45B Underground Truck. In testing, the new control multiple loaders or trucks and achieve LHD has delivered significantly greater even more significant value. productivity than the 20 % increased payload forecasts. The new machine has also
Update on Cat R1700 demonstrated increased fuel efficiency in loadand-carry operations when compared to the
The newest Cat underground loader, the R1700, is completing field testing at a number of mines previous model. around the world and will be commercially
The availability of multiple engine
Drill More configurations enables the loader to be optimised for the application. The R1700
Bits Rods Couplings Shanks DTH with RockMore
Wilsonville, Oregon USA Tel + 1( 503) 682-1001 info @ rockmore-intl. com
R o c k M o r e International
Rock Drilling Tools
®
Mining Construction Quarrying Tunneling Water-well
®
Come See Us at ELKO
Stand 57
Judenburg, Austria Tel + 43 3572-86300 austria @ rockmore-intl. com also can be configured to comply with the highest emission standards in underground applications, helping to improve air quality and potentially reduce ventilation costs.
Caterpillar recently announced the availability of a highly efficient diesel exhaust particulate filter( DPF), a Wall Flow Filter, for its larger LHDs and largest truck. The Wall Flow Filter removes more than 98 % of particulates in the exhaust stream, as compared to the Flow Through Filter, which removes more than 50 %.
The new filter adds another level of
The Cat R1700 has 20 % more payload than the predecessor model
emissions control to the Cat Ventilation Reduction Package, which employs specialised hardware and software to govern the combustion process and reduce emissions and fuel consumption. The Flow Through Filter and Wall Flow Filter offer aftertreatment options and create a system that is scalable to meet the needs of the mining operation. All of the options can be retrofit. Both aftertreatment filter packages require the use of ultra low sulphur diesel fuel and low ash engine oil, but none of the options require the use of diesel exhaust fluid( DEF). Caterpillar suggests contacting the regional Cat dealer for specific recommendations.
The new R1700 also delivers significant technology enhancements. It is equipped with multiple subsystems for fast technology implementation. The Cat MineStar Command system enables operators to work from a remote location and enables the LHD to drive and dump autonomously. Remote machine health monitoring, payload monitoring and other technology options are also available.
For the entire LHD line, Caterpillar is now offering Bolt On Half Arrow GET for bucket edges. The system is designed for high abrasion applications where weld on GET experience high wear rates. With a proven and reliable retention system, the bolt on GET offer more wear material than standard weld on GET, and the bolt on design enables fast and easy removal and replacement. Longer life and faster replacement means less downtime.
The Cat Bolt On Half Arrow GET enhance productivity in additional ways. The segments are designed to minimise carrying weight while keeping the bucket protected, and despite additional wear material, the low profile front edge eases pile penetration and promotes fast bucket loading.
Cavotec HOI on LHDs
Working closely with Atlas Copco and now Epiroc, Cavotec has developed an innovative Human Operator Interface( HOI) system, incorporating long-range wireless
