UTILITY VEHICLES
This image shows the PRINOTH undercarriage which the company sells to mining and exploration companies wishing to control a drill from afar
( 13,200 kg) in its class,“ the PANTHER T14R carrier sets new standards in productivity and mobility and presents a patent-pending innovation called direction reset. This vehicle allows the continuous rotation of the upper portion of the vehicle independent from the undercarriage, allowing the vehicle to work in tight, sensitive areas where other vehicles do not have access.”
Adit Engineering has developed an allpurpose service carrier for either underground or confined space use. The new L-MUVA“ has unparalleled manoeuvrability with 4 t plus load capacity, and is able to turn in one movement in a 4 m wide space. It is extremely stable with a low centre of gravity as well as having a low ground pressure effect. Its skid-steer operation achieves a level of manoeuvrability unmatched by conventional or articulated utility vehicles.”
The L-MUVA is capable of turning 360 ° within a 4.5 m wide roadway making it suitable for a variety of applications where transit space limitations are critical, such as mining. Cited characteristics of the L-MUVA are high availability, and low maintenance and operating cost with minimal skilled labour
intervention. The L-MUVA has been constructed so that it can be reconfigured to many tasks through a day or shift. This is enabled by its mentioned 4 t plus capacity but also using the fitted quick locking attachment. The basic package is a 4.5 m high scissor-lift and an interchangeable, nominal 2 m x 2 m steel tray.
The new L-MUVA says Adit Engineering, has unparalleled manoeuvrability with 4 t plus load capacity, and is able to turn in one movement in a four metre wide space
Adit says it is able to reconfigure modules designed for each mines’ purpose or special duties. Common duties in mining are to transport explosives, ground support elements, fuel or other mine consumables; or as a scissor lift for geological investigation, surveying, explosive charging, mine inspections, or service installations. As a scissor lift it is equipped with vehicle controls and / or levelling facility, with the option of an extended scissor lift of 6.5 m.
It can also be employed as a generator and pump carrier / transport; water tank / foam generator / fire-fighting monitor; or for fitter plant maintenance and servicing / welding. Other special duties for mining include concrete agitator; mine refuge placing and recovery by pick-up or towing; drill carrier or crane.
It is equipped with non-pneumatic tyres and is capable of pulling 40 t of rolling weight. It has no CV joints and no universals with braking primarily by hydrostatic control with supporting wet disc brakes for emergencies and parking. The 100 mm diameter wheel trunnions and bushes provide strength and long service life dependability. It also has high availability, low maintenance and operating cost with minimal skilled labour intervention required, according to Adit.
Normet range address all angles
The Normet range covers underground mining equipment for concrete spraying and transport, explosives charging, scaling, lifting, installation works, and underground logistics. All equipment can also be fitted with European Stage IV / US EPA Tier 4 Final power train technology( Tier 4F). Tier 4F technology is available for all Spraymec concrete
