FRAGMENTATION
Fastec Imaging’ s new TS5 handheld high-speed camera enables users to record all of their mining and blasting operations
fps, there is a TS5 to fit your application needs. All models record over 3,200 fps at VGA resolution and more than 29,000 fps at smaller resolutions. Saving images at ultra-fast speeds to the onboard media while simultaneously recording high-speed bursts of hundreds or even thousands of images at a time, the TS5 is always ready for the next high-speed snapshot. With a base model starting below $ 13,000, the TS5 is a cost-effective solution to record high-speed events for slow motion analysis.”
Tim Brandt, Product Manager for Fastec Imaging, explains that“ because of its highly integrated, handheld design, the TS5 high-speed camera is uniquely suited for recording and playing back slow motion video of blasting events for immediate analysis and confirmation of complete detonation.”
“ Built for flexibility and ease of use, the TS5 can be operated as a self-contained camera or controlled over Gigabit Ethernet via Fastec FasMotion software on your PC / Mac, or via the built-in web interface on your PC, Mac, tablet, or even your smartphone. The FasMotion application makes workflow a breeze with transfers of uncompressed images via Gigabit Ethernet at rates of 50-80 MB / s to most PCs. The TS5 features both a USB port and an SD port for quick and easy image downloads to USB flash drives, SD cards, or portable hard drives. The built-in SSD provides up to 2 TB of lightning-fast non-volatile internal storage.”
High energy proven at Mt Rawdon
The Orica Vistis™ Bulk System is a range of highenergy bulk explosives for use in hard rock metal mines. Vistis produces over three-and-a-half times the detonation pressure and triple the relative bulk strength of ANFO. The energy levels generated, and the speed with which they are released, deliver optimal fragmentation that
[
pulse ] verb reduces overall operating costs either through pattern expansion, without impacting load and haul rates, or by providing broken stock that increases milling efficiency.
The range consists of two primary bulk explosives: Vistis and Vistan™. The Vistis range is designed specifically for wet blasthole applications while the Vistan range is designed for use in dry or dewatered blastholes.
Mt Rawdon is an open pit gold mine located 75 km south-west of Bundaberg in Queensland. It is owned by the Evolution Group, Queensland’ s largest gold producer with its four operating sites. Mt Rawdon is a low-grade mine( 0.71-1.0 g /) yielding approximately 100,000 oz of gold per annum.
to MONITOR the HEALTH of your VIBRATING SCREEN
TYLER PULSE VIBRATION ANALYSIS SERVICE PROGRAM
TYLER PULSE VIBRATION ANALYSIS SERVICE PROGRAM
1-800-325-5993 www. havercanada. com
1-800-325-5993 www. havercanada. com
PROCESSING STORAGE MIXING PACKING FILLING PALLETIZING LOADING
MARCH 2017 | International Mining 13
