GOLD EXTRACTION
Two Mass principle
respond to load surges and increase current capacity limits fit the processing requirements the mine was looking to achieve.
The vibrating STM-SCREEN proposed was designed with two polyurethane decks and a light misting function on the bottom deck for dust suppression. The polyurethane decks allowed rocks that traditionally were easily trapped to wriggle free and not clog the screen. The polyurethane is produced in tiles to allow for easy replacement of damaged segments without replacement of the entire screen section.“ The Two-Mass system allows for the entire screen to handle seven times as much force and capacity as competitive brute force machines,” GK reports.
“ The increased capacity for the Two-Mass system and the durability of the polyurethane screen will be able to run the high capacity and abrasive material with ease and offered a better screening process that yielded increased product quality and consistency.”
Two-Mass refers to a style of vibratory equipment where one mass( an exciter) is used to drive a second mass( trough). The exciter mass
typically contains a motor and is connected to a trough using a combination of springs. Combining the two masses and the springs, a responsive sub-resonant system is created which responds to changes in load without dampening performance.
GK say its Two-Mass system“ requires up to two-thirds less horsepower to achieve the same amount of work as a single mass( brute force) system. This reduction in horsepower significantly reduces energy consumption and related electrical costs. Two-Mass equipment is also more cost effective to maintain, as belts, large motors, and bearings are eliminated.”
Gravity enhancements
Gold miners around the world have had to deal with gold recovery and loss issues for hundreds of years. Unfortunately technology has not kept up with the times for gold miners, according to GoldHog ®.“ It’ s a small industry with little room for technology development and research. This‘ gold loss issue’ often leads to thousands of dollars of placer gold being lost in the waste( tailings) of the miners, especially when it comes to ultra-fine gold.”
GoldHog believes it has finally developed a cure for many gold losses. For over six years the team has been developing and selling new innovative gold recovery mattings for both gold prospectors and miners alike. It now sells in 25 countries and along with the mattings has also developed high efficiency gold recovery equipment. Now the company has introduced a new patent pending gold sluice matting, which it believes will save commercial gold operations from many of these losses.
‘ Doc’, the Founder and CEO, addressed the issues.“ The biggest gold loss factor we see in
commercial gold mining ops is from slurry viscosity issues. Once a plant is running their slurry becomes quiet thick. A thick slurry has a great deal of energy. If you have any turbulence, whatsoever, in a sluice, that creates a strong scrubbing action which will scour out the fine gold. Our new Motherlode Mat™ offers aggressive capture and exchange, but with very little turbulence. Hence it helps to eliminate this common loss issue.”
GoldHog says that by reducing the turbulence in the sluice most operations can increase their capture rates greatly, especially on fine gold. The company works with commercial gold miners around the world and this issue is present everywhere, but is extensive in places like Africa and South America where silts and clays create a heavy mud. In these areas traditional sluices can lose up to 70 % of the fine gold, which has been measured.“ We have seen massive losses of fine gold in commercial ops running thick slurries and they usually don’ t have a choice. Either it’ s the material or limited water supplies that have to be recirculated. Either way this new mat is a dream come true for them. Smooth running, little turbulence, and great capture rates.” IM
The new MotherLode Mat will also be useful in prospecting for gold. This shows various mat profiles
