time monitoring, and its modular design
simplifies installation and
maintenance. The innovative
system offers fast response
and precise control to reduce
conveyor chain wear and
The Cat HTD4100 High Torque Drive System will
start field trials in 2017
Hydraulic travel drives
failures, and the high-torque motors deliver
maximum torque independent of speed to
optimise production while minimising wear."
The new drive system consists of two main
components—a variable frequency converter and
the motor-gearbox combination. In the new Cat
system, a medium voltage converter-controlled
torque motor replaces the AC induction motor.
The control principle of the drive is Direct Torque
Control, which Cat states is the most advanced
AC-drive control technology available.The
converter-controlled torque motor operates at low
speeds, between 0 and 300 rpm versus 1,500 rpm
for induction motors. Lower speed reduces inertia
acting on the output shaft by a factor of eight and
enables the system to react quickly, which
translates to little or no damage to the gearbox
and chain in the event of a conveyor blockage.The
installed motor power of the modular drive
system is 1,250 kW (1,900 hp @ 60 Hz) with
maximum torque of 650,000 Nm (480,000 lb-ft).
“The torque motor design reduces the need for
as many gear stages, which enables the entire
system to be simplified. This in turns allows
smaller dimensions while retaining the same
torque capabilities as systems that are as much
as 20% larger. The smaller size allows flexibility
in laying out longwall entries. The system also
has a reduced number of parts, which enhances
reliability, and the components are standardised
to simplify support of the system.In addition to
soft start and stop, the HTD4100 delivers very
fast acceleration. The variable conveyor chain
speed can be efficiently adapted to the
production conditions - resulting in less wear on
the conveyor. The system also is about 5% more
efficient than conventional drives. The improved
system efficiency means lower energy
consumption and reduced cooling requirements.
Caterpillar also says it will be able to configure
the High Torque Drive System for retrofitting to
existing longwall face conveyors. Plans call for
supplying a range of High Torque Drive Systems
to handle voltages of 3.3 kV or 4.16 kV in a
mechanical power range of 300 kW to 1,600 kW
(400 hp to 2,100 hp). “Systems for additional
applications, such as longwall plough systems
and beam stage loaders, will follow.”
