GOLD EXTRACTION
characteristics of the ore and as well as capital
and operating costs. He illustrated this using the
mentioned Barrick Goldstrike operations where a
number of processes have been applied including
the newly developed thiosulphate leaching
technology.
KellGold
The cyanide-free, low-emissions KellGold process
is capable of high recoveries of gold, silver, base
and rare metals from a range of refractory
concentrates and other materials considered to
be problematic, intractable or otherwise poorly
responding to many conventional treatment
routes. The process was developed for the
extraction of platinum group metals (PGMs) and
base metals from sulphidic flotation
concentrates. Pallinghurst Resources is assessing
potential construction of a full-scale Kell plant to
extract base metals and PGMs at its Sedibelo
Platinum Mines subsidiary.
The KellGold process consists of several
commercially proven unit operations and utilises
know-how gained from the processing of PGM
concentrates. The process has been applied
successfully to refractory gold and copper-gold
concentrates and other gold-bearing materials
such as calcine-leach tailings where cyanidation
recoveries are low. Reagent consumers and
valuable byproducts such as S, Cu, Ni and Co are
first selectively removed by use of a pressure
oxidation step during
which the dissolution of
precious metals is
minimised. High
recoveries of gold and
silver are achieved by
subsequent chlorination,
with typically low reagent
consumptions due to
prior removal of reagent
consumers and the use of
efficient lixiviant
recycling. The core steps
within KellGold are
similar to well-proven
conventional unit
operations in common
use elsewhere, as are the
subsequent metal recovery steps to provide
marketable high-purity primary and secondary
end products such as refined metal sponges,
bars or coins. In this way, third-party smelting,
treatment, transportation and refining costs are
removed from the value chain, with saleable
metals being produced on the mine site.
Residues have similar characteristics to flotation
tailings and may be co-disposed. A Kell plant can
be constructed close to the mine site, removing
the often costly transportation and wharfage
costs for shipping concentrate.
The process generally consumes significantly
Kell process
flow chart
less energy, less electricity, and requires lower
capital and operating costs than the equivalent
conventional smelting and refining facilities for
the same duty. Unlike conventional smelters or
bioleaching plants, for example, which lock up
considerable gold and other precious metals in
circuit, the Kell process locks up substantially
less metal inventory and hence, releases
significant working capital early in the project,
sometimes enough to pay for most of the plant
capital costs.
The costs of cyanide detoxification and
management are avoided, as are the risks
