IIC Journal of Innovation | Page 94

More Horsepower with the Click of a Download needs to be used for software as well, when the software failure would be impacting critical systems. Automotive Safety Integrity Level D (ASIL-D), for example, refers to the highest classification of initial hazard (injury risk) defined within ISO 262623 and to that standard’s most stringent level of safety measures to be applied to avoid an unreasonable residual risk. 2.2 Car Management = Mobility Management Modern cars are mobile devices on wheels, underpinned by systems of many devices on wheels that contain dozens and even hundreds of Electronic Control Units (ECUs) which amongst them run a hundred million lines of code and are connected via vehicle bus systems and gateways. One endpoint of the busses is the Onboard Diagnostic Port (OBD II), which can usually be found under the steering wheel. The electronics in cars significantly contribute to R&D and production costs and, as mentioned before, there is not much reuse in this area. Functionalities such as Navigation, real time traffic information, Calendaring, and email have over the years been added to the Head Unit which in the early years were only extensions for the radio and audio systems. This also explains why these systems are so vulnerable as soon as they connect to the Internet. Software code for the above-mentioned functions has been added incrementally to an already monolithic software system and therefore creates a large attack surface4. Without a complete, secure and modular redesign of the Head Unit software, the best approach for a solution today is to secure the connection from the vehicle backend to the car in the same way it is done on mobile devices; with a vir X[
