Automotive Security through New Communication Lockdown
o Another process
o Different partition
o Reside on a different operating
system
o Reside on a different processor
Software - Service Oriented Architecture
(SOA)
SOA partitioning 7 utilizes the patented
architecture
allowing
for
unified
communication as well as access control and
service level partitioning. Using a separation
kernel allows for abstraction and
concealment of communications across the
platform, this allows for simplified and
transparent interface to service providers.
Service providers include but not limited to:
Furthermore, CORBA brokers may be used in
order to standardize service access across
the platform.
Centralized Management
Centralized Security Services
Unified Communication Infrastructure
Hypervisor
Separation Kernel
Secure Hardware with Network Seperation
Figure 3: Services Oriented Architecture
7
GuardKnox Distributed SOA Patent “Specially Programmed Computing Systems with Associated Devices Configured to
Implement Centralized Services ECU Based on Services Oriented Architecture and Methods of Use Thereof
”http://appft.uspto.gov/netacgi/nph-Parser?Sect1=PTO2&Sect2=HITOFF&p=1&u=%2Fnetahtml%2FPTO%2Fsearch-
bool.html&r=3&f=G&l=50&co1=AND&d=PG01&s1=GuardKnox&OS=GuardKnox&RS=GuardKnox”
- 63 -
March 2019
