GEODYNA® RANGE
TRUCK
WHEEL
BALANCERS
geodyna 980L - EEWB710AE1
Truck balancer with eye level VDU display and
optional wheel lift.
Scope of application:
Commercial vehicle tyre shops large tyre shops.
Features
• VPM (virtual plane measuring)- enhanced
measuring to give higher accuracy results
• Automatic start of measurement when
hood closed & brake applied at end of
spin cycle
• Robust 40mm shaft
• 5 different options for weight positioning
on wheel
• 2D SAPE - Automatic entry of wheel
diameter, and wheel distance
• Guided weight positioning in Alu mode using gauge arm weight applicator
• Split weight mode - Hide weights
behind wheel spokes for more appealing
cosmetic finish
• Tyre matching mode - optimise tyre to rim
so using less weights
• Tapered shaft
Te c h n i c a l S p e c i f i c a t i o n
Optional
Measuring speed
<100 rpm
may be needed to cover all wheel types:
Rim width setting range
2 - 20"
• Pre-centring ring
Rim diameter setting range
8 - 26"
Max. wheel width
650 mm
Max. wheel diameter
1300 mm
Max. wheel weight
250 kg
Dimensions (HxWxD)
2005 x 1370 x 1455 mm
Weight of machine
235 kg
Power supply
200 - 240V 1ph 50 / 60 Hz
• Clamping kit with 2 truck cones
• PRO clamping kit for stud hole
w w w. s n a p o n - e q u i p m e n t . c o . u k
