F A S T. A C C U R A T E . E A S Y. P R O F I T A B L E
P R I S M
R A N G E
GEOLINER 580 PRISM ELITE - EEWAEU717BE1
Introducing the Geoliner 580 Prism. Accurate, flexible, easy
to service. Do alignments quickly from virtually anywhere in
your shop. Reduce the time required to perform corrective
actions and rely on advanced, lightweight components that
are designed with the technician in mind.
PRO 42 is a high-resolution ICON based software program
designed to provide the most effective use of information
required by the technician. It has ALL the required functions
in a one-touch program format to allow the technician to
provide accurate and fast alignments. With its unique
DIAGNOSTIC information it allows the technician to easily
understand vehicle problems.
Rolling run-out compensation of the vehicle
With this software feature it is possible to perform runout compensation without jacking up the vehicle. It is only
necessary to roll the vehicle back and forth.
Owing to this feature there is no need for changing vehicle
height so that the analysis of measured data is absolutely
clear to the operator. It is also possible to perform a fourwheel split position run-out compensation if the vehicle being
measured is too long for the rack.
Measurement of vehicle dimensions
This feature allows to measure set-back on front and rear as
well as the wheel base. Wheel track difference of front and
rear axles is also measured, the result is read out as axle offset.
Those quick diagnostic features are an optimum supplement
for customer services.
Te c h n i c a l S p e c i f i c a t i o n
• indows operating system
W
• niversal wheel clamp 11" - 22"
U
(26" with adaptor)
• teering wheel holder
S
• rake pedal depressor
B
• an be calibrated to THREE
C
work areas
Yes
11 - 22"
Wheel base
• ackup/Restore of calibration
B
& setup data
Caster and SAI
1200 - 5000 mm
Ride height modified vehicle specs
• Computerised 4 wheel aligner
Yes
Clamping range
Features
Toe-out on turns
Yes
Camber and toe turntable (caster frozen) Yes
Camber and toe elevated (caster frozen)
Yes
Rear shims
Yes
Display / monitor
19" TFT
• ools, parts & adjustment
T
instructions
Communication
Bluetooth
Measuring system
Pods
• dvanced customer database
A
Power supply
230 VAC 1ph 50/60 Hz
• ntegrated help system
I
• D animations
3
• ultiple print formats
M
• Long battery life
• Printable before & after results
• ehicle specifications – 25+ years
V
• ultiple units of measure
M
• ustom vehicle specifications
C
• qualize toe adjustment
E
• ligner system diagnostics
A
• Rolling run out compensation
Options
• ront radius plates and rear slip plates available
F
for existing 4 post lifts. Price on application
