ExpertNEWS | No.1 | January 2015
DIESEL TOOLS
DELPHI
BOSCH
DENSO
SIEMENS
ART. 311166010
Injector removing Master kit 38 pcs
Specific for disassembling very stuked injectors
Due to fouling caused by burning the injector is locked
and can not be removed without a proper tool
The universal supporting feet adjustment, on the
fixing screws of the head, ensures its use in
different levels (l/r) as well as the possibility to
adjust the slippage of the two side bars
Upgrade option for hydraulic pump and
hydraulic cylinder
Double action for connected injectors possible:
Mercedes Benz, Opel, Fiat
Technical sheet
Download
UPGRADE OPTION
12 TO
ART. 270022000
Go-through mechadraulic
cylinder
+
UPGRADE OPTION
12 TO
ART. 270019000
Go-through hydraulic cylinder
Dimensions:
Dimensions:
Stroke:
8 mm
Driving torque:
T h i l h
Technical sheet
Download
for spindles up to Ø 21.5 mm
Stroke:
for spindles up to Ø 21.5 mm
8 mm
Technical sheet
Download
Pressure:
700 Bar
67Nm
Weight:
2,02 Kg
Weight:
2.5 Kg
Size:
Ø 80 X 55 mm
Size:
Ø 80x55 mm
Connection:
F 3/8”
Working independent without pump
BOSCH
DELPHI
DENSO
SIEMENS
+
ART. 311184000
UPGRADE OPTION
Tool set for injector removal with slide hammer 7 pcs
This kit allows injector removal with two distinct procedures
OPTION 1: Use the pliers with holding arms which is perfectly
fitting into the shape of the injector
MERCEDES
ART. 311179003
Fork extractor with adapter
M12 - M18x1.5
for removing piezoelectric injectors on
Mercedes Benz OM 651 engines
OPTION 2: Use the articulated joint adapter and the pivot,
which has to be screwed to the fitting of the Common Rail duct
Disassembling the injector head is not necessary
OPTION 1:
Use with pliers
OPTION 2:
Use with articulated joint
APPLICATION INJECTORS PIEZOELECTRIC:
Models:
Mercedes Benz
Engine:
Technical sheet
Download
200 CDI, 220 CDI, 250 CDI
Engine codes:
channel
OM 651
APPLICATION DELPHI PIEZO AND DELPHI
DFI 1.5 (EURO 5):
Injector codes:
Technical sheet
Download
EMBR, EJBR (cars) and EJDR
(commercial vehicle)
Models:
THETOOLMAKER
+
Hydraulic pump
you can find on
page 2
Mercedes Benz, Hyunday
and Kia
