* DC/DC converters especially at high switching frequencies
ESD suppressor
Characteristics:
* Fast response time
* No leakage current
* Low clamping voltage
* Almost no energy consumption in stand-by mode
* Excellent absorption for ESD-impulses
* Operating temperature: –40 ºC to 85 ºC
* Nickel barrier
Applications:
* Protection of bus systems
* Protection of semiconductors
* ESD protection in accordance with EN 61000-4-2:
– 8 kV contact discharge
– 15 kV contact discharge
DIP switch
DIP switch cont.
MATERIAL Insulator: PBT / PA66
* Protection of data lines
