Market Leading Access Control Solutions
Network Access Control System
Central Station
1
One Door
2
Two Door
4
Four Door
Two Way Controller
SKU# ACP3100P
Network Access Control Central Station Package. includes
Metal box and Power supply. Recommended: Connect a back
up battery.
One door, two-way controller event buffer: 100,000; reader
input port 2 each one (26 / 34 bits Wiegand, 8 bits burs for PIN)
Communication RS 485 TCP / IP, Input Port: 2 each one (1 exit
button, 1 door sensor) Output Port 2 Each one (1 Form C Relay
Output for lock and 1 Auxiliary Form C Relay Output).
SKU# ACP3200P
Network Access Control Central Station Package.
includes Metal box and Power supply. Recommended:
Connect a back up battery
Two door, two-way controller event buffer: 100,000;
reader input port 2 each one (26 / 34 bits Wiegand, 8
bits burs for PIN) Communication RS 485 TCP / IP, Input
Port: 2 each one (2 exit button, 2 door sensor) Output
Port 2 Each one (2 Form C Relay Output for lock and 1
Auxiliary Form C Relay Output)
2
1
SKU# ACP3100
One door, two-way controller event buffer: 100,000;
reader input port 2 each one (26 / 34 bits Wiegand, 8
bits burs for PIN) Communication RS 485 TCP / IP, Input
Port: 2 each one (1 exit button, 1 door sensor) Output
Port 2 Each one (1 Form C Relay Output for lock and 1
Auxiliary Form C Relay Output)
1
12
SKU# ACP3400P
Network
Access
Control
Central
Station
Package. includes Metal box and Power supply.
Recommended: Connect a back up battery
Four door, two-way controller event buffer: 100,000;
reader input port 4 each one (26 / 34 bits Wiegand,
8 bits burs for PIN) Communication RS 485 TCP / IP,
Input Port: 12 each one (4 exit button, 4 door sensor, 4
Auxiliary Input) Output Port 8 Each one (4 Form C Relay
Output for lock and 4 Auxiliary Form C Relay Output)
4
SKU# ACP3400
SKU# ACP3200
Two door, two-way controller event buffer: 100,000;
reader input port 2 each one (26 / 34 bits Wiegand, 8
bits burs for PIN) Communication RS 485 TCP / IP, Input
Port: 2 each one (2 exit button, 2 door sensor) Output
Port 2 Each one (2 Form C Relay Output for lock and 1
Auxiliary Form C Relay Output)
2
Four door, two-way controller event buffer: 100,000;
reader input port 4 each one (26 / 34 bits Wiegand,
8 bits burs for PIN) Communication RS 485 TCP / IP,
Input Port: 12 each one (4 exit button, 4 door sensor, 4
Auxiliary Input) Output Port 8 Each one (4 Form C Relay
Output for lock and 4 Auxiliary Form C Relay Output)
4
