CHAPTER 22 ADO.NET PART II: THE DISCONNECTED LAYER
Using the disconnected layer, it is possible to model relational data using an in-memory object
model. Far beyond simply modeling a tabular block of rows and columns, the types within System.Data
allow you to represent table relationships, column constraints, primary keys, views, and other database
primitives. After you model the data, you can apply filters, submit in-memory queries, and persist (or
load) your data in XML and binary formats. You can do all of this without ever making a literal
connection to a DBMS (hence the term, disconnected layer) by loading data from a local XML file or
manually building a DataSet in code.
Note In Chapter 23, you will examine the ADO.NET Entity Framework, which builds upon the concepts found in
the disconnected layer examined here.
You could use the disconnected types without ever connecting to a database, but you will typically
still use connection and command objects. In addition, you will leverage a specific object, the data
adapter (which extends the abstract DbDataAdapter class), to fetch and update data. Unlike the
connected layer, data obtained with a data adapter is not processed using data reader objects. Rather,
data adapter objects use DataSet objects (or more specifically, the DataTable objects in a DataSet) to
move data between the caller and data source. The DataSet type is a container for any number of
DataTable objects, each of which contains a collection of DataRow and DataColumn objects.
The data adapter object of your data provider handles the database connection automatically. In an
effort to increase scalability, data adapters keep the connection open for the shortest amount of time
possible. After the caller receives the DataSet object, the calling tier is completely disconnected from the
database and left with a local copy of the remote data. The caller is free to insert, delete, or update rows
from a given DataTable, but the physical database is not updated until the caller explicitly passes a
DataTable in the DataSet to the data adapter for updating. In a nutshell, DataSets allow the clients to
pretend they are always connected; however, they actually operate on an in-memory database (see
Figure 22-1).
Figure 22-1. Data adapter objects move DataSets to and from the client tier
Given that the centerpiece of the disconnected layer is the DataSet class, the first task of this chapter
is to learn how to manipulate a DataSet manually. Once you can do this, you will have no problem
manipulating the contents of a DataSet retrieved from a data adapter object.
