CHAPTER 15 TYPE REFLECTION, LATE BINDING, AND ATTRIBUTE-BASED PROGRAMMING
Examining a TypeRef
Recall that an assembly’s metadata will describe not only the set of internal types (Car, EngineState,
etc.), but also any external types the internal types reference. For example, given that CarLibrary.dll has
defined two enumerations, you find a TypeRef block for the System.Enum type, as follows:
TypeRef #1 (01000001)
------------------------------------------------------Token:
0x01000001
ResolutionScope:
0x23000001
TypeRefName:
System.Enum
Documenting the Defining Assembly
The ildasm.exe metadata window also allows you to view the .NET metadata that describes the assembly
itself using the Assembly token. As you can see from the following (partial) listing, information
documented within the Assembly table is (surprise, surprise!) the same information that can be viewable
via the MANIFEST icon. The following is a partial dump of the manifest of CarLibrary.dll (version
2.0.0.0):
Assembly
------------------------------------------------------Token: 0x20000001
Name : CarLibrary
Public Key
: 00 24 00 00 04 80 00 00 // Etc...
Hash Algorithm : 0x00008004
Major Version: 0x00000002
Minor Version: 0x00000000
Build Number: 0x00000000
Revision Number: 0x00000000
Locale:
Flags : [PublicKey] ...
Documenting Referenced Assemblies
In addition to the Assembly token and the set of TypeDef and TypeRef blocks, .NET metadata also makes
use of AssemblyRef #n tokens to document each external assembly. Given that the CarLibrary.dll makes
use of the System.Windows.Forms.MessageBox class, you find an AssemblyRef for the
System.Windows.Forms assembly, as shown in the following code:
AssemblyRef #2 (23000002)
------------------------------------------------------Token: 0x23000002
Public Key or Token: b7 7a 5c 56 19 34 e0 89
Name: System.Windows.Forms
Version: 4.0.0.0
Major Version: 0x00000004
Minor Version: 0x00000000
Build Number: 0x00000000
Revision Number: 0x00000000
Locale:
559
