The individually configurable TL 305-IOL tower lights can be parameterized extremely flexibly via the IO-Link interface . System operators can signal individual machine states by means of different brightnesses , lighting sequences , colors or types of signal sound .
Clearly visible light signals
Leuze introduces new tower lights in robust aluminum housing onto the market : The TL 305 series impresses with bright and homogeneous illumination as well as an optional IO-Link interface .
Tower lights are indispensable in machine and system construction as well as in intralogistics : They make states , faults , and ongoing processes
clearly visible from a distance . The new Leuze tower lights of the TL 305 series can do all of this extremely reliably . They light up brightly , uniformly , and fully . This enables optimum signaling – whether at the machine , on the conveyor belt , or for access control . The compact towers are available preconfigured with three , four , or five segments . The new range of tower lights includes the TL 305 models with a predefined color assignment as well as the TL 305-IOL models with an IO-Link interface . The IO-Link variants allow different operating modes and provide an extensive selection of colors . On request , the tower lights are also available with an additional acoustic signaler .
QUICK AND EASY IMPLEMENTATION
System operators benefit from the immediate usability of the tower lights . The M30 thread and M12 connectors make them easy to install . Matching 106 FDPP - www . fdpp . co . uk accessories simplify installation . All models of the series are characterized by a highquality and robust design . The aluminum housing allows the tower lights to be used even in demanding industrial environments .
FLEXIBLE CONFIGURATION
The IO-Link version TL 305-IOL with its different operating modes offers maximum flexibility . Segment mode enables the segments to be actuated individually via IO-Link . This allows color , intensity , and lighting sequences to be configured individually . Level mode
The IO-Link variants allow different operating modes and provide an extensive selection of colors .
is used to visualize fill levels . If fast commissioning is required , users can actuate eight predetermined or userdefined configurations via the three external trigger inputs even without an IO-Link connection .
www . leuze . com
The TL 305 tower lights used in combination with a proximity sensor are also suitable for safety-related monitoring tasks . For example , if a door is opened , a visual and / or acoustic warning is output .
