Audi plant compares back plate to wiring frame
Figure 1
With the advancement of power electronic components in general gives rise to increased heat dissipation , resulting in more hotspots within control cabinets where traditional methodology of construction is employed . Separating the wiring from the components allows for free air movement , resulting in passive cooling within the cabinet .
A live on-site test was conducted to prove effectiveness of this approach . The first cabinet was equipped with a traditional back plate and cooled using an air conditioning system with a 1.5 kW heat loss . In the second cabinet a 1.45kW heat exchanger was fitted , and the mounted components were separated from the wiring using the Lutze AirSTREAM wiring frame . ( shown in figure 1 ).
Measurements were taken for six hours at a time in each cabinet . The measurements were carried out over two days , with 10 sensors recording the ambient and internal temperatures . In the cabinet using the back plate the temperatures fluctuated between 29 degrees C and 43 degrees C . In the cabinet using AirSTREAM , the temperatures fluctuated between 30 degrees C and 34 degrees C ( as shown in figure 2 ). The test demonstrated that using AirSTREAM can achieve noticeable cooling and a consistent climate inside the control cabinets . This not only protects the components but reduces the amount of energy needed to cool the cabinets .
Figure 2
Visit https : / www . luetze . com / en-gb / airstream-climb-c for more information .
