Our range of quality cam locking couplings from own
production are guaranteed to EN 14420-7, reliable, leak-
proof, durable and offer better product properties than
most Cam and Groove Couplings you will find on the
market:
• Wall thickness and tolerances to standard
• Material specification to standard ( stainless steel,
aluminium, brass )
• Machined inner surfaces < Ra 1,6
• Ergonomic, contour shaped levers, optimised lever
geometry for improved coupling safety
• PN 16 bar for all materials, ( DN 10: 10 bar )
• Manufacturer‘s liability: clear Elaflex and batch
marking for traceability
• Inspection test certificates EN 10204 - 3.1 available
on request
• Easy attachment with standardised hook spanner
Robust lever
attachment and
ergonomic, contour
shaped levers for
improved coupling
safety
New
Quality of
Cam Locking
Couplings
('Camlock')
The product range is available from DN 19 to DN 100,
depending on the type of material : stainless steel (also
with PFA coating) brass or aluminium. Available with
integrated hose tail, as threaded version or weld-on type.
Safe, Easy ... EASYLOC®
Camlock female couplers are now also available in
'EASYLOC' version with automatic lever lock. Unwanted
opening of the levers and disconnection during operation,
e. g. due to excessive vibration, pulsation or accidental
disengagement due to operator error is safely prevented.
The operation is easy and self-explanatory. 'EASYLOC'
cam locking couplers are made of stainless steel and can
be ordered in the sizes from DN 19 until DN 50.
Closing: automatic lever lock.
Opening: pull eyelet to unlock.
tion :
More informa
/camlock
elaflex .de /en
tion :
More informa
/easyloc
elaflex .de /en
