EQUIPMENT
Warmers
Top Mount Drop-in
Food WARMERS
by Wells ®
TOP MOUNT DROP-IN
Food WARMERS
by APW WYOTT ®
Fully insulated on all four walls and bottom,
resulting in a quicker preheat, faster
recovery, and energy savings. Provide even heat distribution with a circular
designed heating element. Feature EZ locks for
easy installation and EZ-Fill self-regulating water
fill system.
No. 173-1143
• Model HMP6
• Requires 20 5 ⁄ 8 " x 6 3 ⁄ 8 " W (676mm x 162mm)
counter opening
• Accepts 6" x 20" (152mm x 508mm) half-size
pan or equivalent fractional size pans
• 120 volt, 750 watt
• Includes thermostat (No. 173-1062) and
dial (No. 173-1098)
• Stainless steel well
• Control can be mounted up to
26" (660mm) from warmer
• Stainless steel well
7 QT
(6L)
INSET
• 10 1 ⁄ 2 " OD (267mm)
• Requires 8 3 ⁄ 4 " (222mm) OD opening
• 120 volt, 800 watt
No. 160-1087 With drain
• Model SM-50-SD (50826)
• 8 1 ⁄ 8 " (206mm) high
• 1 ⁄ 2 " NPT female drain outlet
Designed for wet or dry applications.
Constructed of stainless steel for maximum
strength and durability.
• 12" OD x 8 3 ⁄ 4 " deep (305mm x 222mm)
• Requires 11" (279mm) opening
• Control can be mounted up to
24" (610mm) from warmer
• 120 volt
• Stainless steel well
No. 173-1126 Infinite control (not shown)
• Model SS10-120
• 450 watt
No. 173-1127 Thermostat control
• Model SS10TDU-120
• 825 watt
• Includes 1 ⁄ 2 " NPT female drain outlet
No. 160-1322 Without drain
• Model SM-50-7 (50825)
• 8 1 ⁄ 2 " (216mm) high
11 QT
(10L)
INSET
• 12 1 ⁄ 2 " (318mm) OD
• Requires 10 3 ⁄ 4 " (273mm) OD opening
• 1" (25mm) flange
No. 160-1246 120 volt, 800 watt with drain
• Model SM-50-11D (50828)
• 7 3 ⁄ 4 " (197mm) high
• 1 ⁄ 2 " NPT female drain outlet
Drawer Pans
ITEM No.
132-1077
132-1079
132-1078
132-1080
FITS
DRAWER SIZE
15" x 20" x 5" MATERIAL
Stainless steel
20" x 20" x 5" Stainless steel
15" x 20" x 5" Thermoplastic
20" x 20" x 5" Thermoplastic
(381mm x 508mm x 127mm)
(508mm x 508mm x 127mm)
(381mm x 508mm x 127mm)
(508mm x 508mm x 127mm)
Phone: 800-257-7737
No. 160-1321 120 volt, 800 watt
without drain
• Model SM-50-11 (50827)
• 8 1 ⁄ 8 " (206mm) high
No. 160-1319 208/240 volt, 500/660 watt
with drain
• Model SM-50-11D (55370)
• 8 1 ⁄ 8 " (206mm) high
• 1 ⁄ 2 " NPT female drain outlet
No. 160-1320 208/240 volt, 500/660 watt
without drain
• Model SM-50-11 (51020)
• 8 1 ⁄ 8 " (206mm) high
24-Hour Fax: 800-255-9866
TOP MOUNT Drop-in
food WARMER
by APW WYOTT ®
Features EZ locks for easy installation.
No. 160-1318
• Model HFW-1D-120V (56445)
• 120 volt, 1500 watt
• Requires 13 7 ⁄ 8 " x 21 7 ⁄ 8 " opening
• Control can be mounted up to 26"
from warmer
• ½" NPT female drain outlet with
removable screen
• Stainless steel well
899
TOP MOUNT Drop-In
Food WARMER
by WELLS ®
