Heavy-Duty Baffle FILTERS
by FLAME GARD ®
TYPE III BAFFLE GREASE FILTERS
Unique frameless design maximizes the available capture area and increases each
filter’s free area. Feature low static pressure.
• Furnished with handles
• 2" (51mm) nominal thickness, 1 5 ⁄ 8 " (41mm) actual thickness
• Approved by City of New York Department of Buildings, certificate no. 5627
• Meets NFPA No. 96 criteria and requirements
• Stainless steel
• Height measurement is direction of baffles
No.
No.
No.
No.
No.
No.
No.
No.
129-2111
129-2112
129-2113
129-2114
129-2115
129-2116
129-2117
129-2118
10"
12"
16"
18"
20"
20"
25"
25"
H
H
H
H
H
H
H
H
x
x
x
x
x
x
x
x
20"
20"
25"
18"
16"
25"
16"
20"
W
W
W
W
W
W
W
W
(254mm x 508mm)
(305mm x 508mm)
(406mm x 635mm)
(457mm x 457mm)
(508mm x 406mm)
(508mm x 635mm)
(635mm x 406mm)
(635mm x 508mm)
Note: Dimensions for height and width
are nominal—actual dimensions
are approximately 1 ⁄ 2 " (13mm)
less. For example, a 20" x 20"
(508mm x 508mm) filter is actually
19 1 ⁄ 2 " x 19 1 ⁄ 2 " (495mm x 495mm) .
type II Heavy-Duty stainless steel
baffle grease filters
Feature heavy gauge stainless steel with double-framing that resists all dents and bending,
even if dropped. All filters have attached end baffles for greater efficiency.
• Furnished with drop handles
• Approved by the City of New York Department of Buildings MEA 137-82-M
• Meets NFPA no. 96 criteria and requirements
• Patent no. 3910782
• 2" (51mm) nominal thickness, 1 3 ⁄ 4 " (44mm) actual thickness
• Height measurement is direction of baffles
No. 129-1184 16" H x 20" W
No. 129-1185 20" H x 20" W
No. 129-1186 25" H x 20" W
(406mm x 508mm)
(508mm x 508mm)
(635mm x 508mm)
Type I Heavy-Duty Grease Filters
Exclusive spark arrestor screen helps prevent airborne sparks and embers
from entering the hood and duct system.
Feature heavy gauge nickel-plated steel double framing that resists dents and bending,
even if dropped. All filters have attached end baffles for efficiency. Baffles are coated to
resist grease build-up and are easy to clean.
• Furnished with drop handles
• Meets NFPA no. 96 criteria and requirements
• 2" (51mm) nominal thickness, 1 7 ⁄ 8 " (48mm) actual thickness
• Height measurement is direction of baffles
No.
No.
No.
No.
No.
No.
No.
No.
No.
No.
No.
129-1097
129-1050
129-1096
129-1059
129-1051
129-1052
129-1053
129-1054
129-1055
129-1056
129-1057
10"
10"
12"
16"
16"
16"
20"
20"
20"
25"
25"
H
H
H
H
H
H
H
H
H
H
H
x
x
x
x
x
x
x
x
x
x
x
16"
20"
20"
16"
20"
25"
16"
20"
25"
16"
20"
W (254mm x 406mm)
W (254mm x 508mm)
W (305mm x 508mm)
W (406mm x 406mm)
W (406mm x 508mm)
W (406mm x 635mm)
W (508mm x 406mm)
W (508mm x 508mm)
W (508mm x 635mm)
W (635mm x 406mm)
W (635mm x 508mm)
No. 129-1224 Replacement drop handle
Phone: 800-257-7737
U-shaped baffles cause grease to drain
off the filter quickly.
Note: Dimensions for height and width
are nominal—actual dimensions
are approximately 1 ⁄ 2 " (13mm)
less. For example, a 20" x 20"
(508mm x 508mm) filter is actually
19 1 ⁄ 2 " x 19 1 ⁄ 2 " (495mm x 495mm) .
24-Hour Fax: 800-255-9866
21
cooking accessories
