All the Great
Features of the
Original Franklin Filter ®
Hinged Hood Filter:
HIGH EFFICIENCY HOOD FILTERS
These easy-to-clean filters
are an investment in
hood safety and efficiency.
“Cleanliness is...”
• Hinged design allows for
– easier cleaning
– the most thorough cleaning possible––like new
– reduced threat of fire
“A Penny Saved...”
• Unique, slotted baffles reduce static pressure, creating
– less strain on fan motor
– greater heat removal
– quieter operation
PLUS...
Slotted Baffles
• Specially designed baffle channel screens for maximum grease removal
– Up to 50% more grease removal than standard baffle filters
– Superior filtering captures grease particles as small as 2 microns
• Stronger hinges
• Meets NFPA no. 96 criteria and requirements
• Tested to ASTM-F2519 criteria and requirements
• Patent nos. 7571721, 7581539
• ETL Listed to UL-1046 and UL-S649
• ETL Sanitation Listed to NSF standards
• Stainless steel
• Height measurement is direction of baffles
129-1227
129-1228
129-1229
129-1230
129-1231
129-1232
129-1233
129-1234
129-1235
12" H x 16" W (305mm x 406mm)
12" H x 20" W (305mm x 508mm)
16" H x 16" W (406mm x 406mm)
16" H x 20" W (406mm x 508mm)
16" H x 25" W (406mm x 635mm)
20" H x 16" W (508mm x 406mm)
20" H x 20" W (508mm x 508mm)
20" H x 25" W (508mm x 635mm)
25" H x 20" W (635mm x 508mm)
Baffle Channel
Screens
Superior grease extraction *
100
No.
No.
No.
No.
No.
No.
No.
No.
No.
Stronger Hinges
Note: Dimensions for height and width are nominal—actual dimensions
are approximately 1 ⁄ 2 " (13mm) less. For example, a 20" x 20"
(508mm x 508mm) filter is actually 19 1 ⁄ 2 " x 19 1 ⁄ 2 " (495mm x 495mm) .
The
Franklin
Filter
Plus ®
HOOD
Filter
90
80
70
60
50
STANDARD
BAFFLE
FILTER
40
30
20
10
0
0
2
4
6
8
Particle Diameter (µm)
10
*Tested to ASTM-F2519 Standards Requirements
