TIMErs & Thermometers
TEMPERATURE ALARMS
Provides warnings, a blinking light, and a
buzzer. Buzzer has a delay to prevent false
alarms.
No. 138-1028
• – 40° to 160°F (– 40° to 71°C) alarm
adjustment range
• 120 to 12 volt adaptor
• 6' (1829mm) sensor and power cords
• 3 1 ⁄ 4 " H x 4 3 ⁄ 4 " W x 1 1 ⁄ 2 " D
(83mm x 121mm x 38mm)
• Includes battery backup (9 volt battery not
included) and terminal connections for remote
alarm or automatic phone dialer
Temperature Alarm
Provides warnings, a blinking light, and a
buzzer. Buzzer has a delay to prevent false
alarms. The alarm can be set to activate when
the temperature inside a refrigerator or freezer
is above or below the optimum range.
No. 138-1029
• 120 volt
• – 10° to 80°F alarm adjustment
• 6' sensor and power cords
• 4 7 ⁄ 8 " H x 3" W x 1 5 ⁄ 8 " D
• Includes terminal connections for remote
alarm or automatic phone dialer
• High-impact plastic housing
• Fahrenheit scale only
1
2
3
ALARM AND LIGHT
MONITORS
Reduce energy costs with these programmable
monitors that control temperatures and automatic
On/Off light management.
• For walk-in coolers and freezers
• 6 3 ⁄ 8 " H x 3 3 ⁄ 4 " W x 2 5 ⁄ 8 " D (162mm x 95mm x 67mm)
• – 40° to 230°F (– 40° to 110°C) temperature range
• 120 volt
• Uses probe (Nos. 138-1225 or 138-1226,
not included)
• 9 volt battery back-up (battery not included)
• High/Low temperature alarm with delay
• Monitor waterproof to IP65
• Meets 2008 Federal Energy Independence Act
Section 312
1. No. 138-1222 Monitor with external buzzer
• Includes wall mounting box
Economy
Temperature Alarm
Loud alarm will sound when set temperature
is exceeded. Features a delay switch, used to
prevent false alarms.
No. 138-1060
• – 10° to 80°F alarm adjustment range
(Fahrenheit scale only)
• Uses 9 volt battery (not included)
• 6' sensor lead
• 4 5 ⁄ 8 " H x 1 3 ⁄ 4 " W x 7 ⁄ 8 " D
• High-impact plastic housing
Temperature/Humidity
Thermometer
by Acu-Rite ® 2. No. 138-1223 Monitor with internal buzzer
• Used with existing junction box
No. 138-1217
• 3 3 ⁄ 4 " H x 2 5 ⁄ 8 " W x 1" D (95mm x 67mm x 25mm)
• Uses 2 AAA batteries (not included) 3. No. 138-1224
• Used with alarm and light monitors
(Nos. 138-1222 and 138-1223)
• Normally open
• Includes mounting hardware
MAGNETIC DOOR SWITCH
TEMPERATURE PROBES (not shown)
• Used with alarm and light monitors
(Nos. 138-1222 and 138-1223)
No. 138-1225 60" (1524mm) overall length
No. 138-1226 96" (2438mm) overall length
No. 253-1242 9 volt battery
No. 253-1242 9 volt battery
Temperature alarms provide 24-hour protection against costly food spoilage
caused by temperature changes in refrigerators and freezers.
Phone: 800-257-7737
24-Hour Fax: 800-255-9866
599
Temperature Alarm
with Digital Thermometer
