rocker switches
Rocker Switches
1
2
• Fits 7 ⁄ 16 " x 3 ⁄ 4 " (11mm x 19mm) opening
REF
No. ITEM No.
CONNECTIONS
1
2 tab terminals, 1 ⁄ 4 "
227-1134 (6mm) ACTION
SPST On/Off 125V RATING
– 250V RATING 277V RATING
16 amp
10 amp
• Fits 7 ⁄ 8 " x 1 1 ⁄ 8 " (22mm x 29mm) opening
REF
No. ITEM No.
CONNECTIONS
2
6 tab terminals, 1 ⁄ 4 "
800-8038 (6mm) ACTION
125V RATING
DPDT On/Off/On
20 amp 250V RATING 277V RATING
16 amp
–
ACTION
SPST On/Off 125V RATING
15 amp 250V RATING 277V RATING
8 amp
–
• Fits 11 ⁄ 16 " x 1 ⁄ 2 " (17mm x 13mm) opening
REF
No. ITEM No.
CONNECTIONS
3
2 tab terminals, 3 ⁄ 16 "
124-1463
3
4
5
6
7
(5mm)
• Fits 7 ⁄ 8 " x 1 1 ⁄ 2 " (22mm x 38mm) opening
REF
No. ITEM No.
CONNECTIONS
4
6 tab terminals, 1 ⁄ 4 "
165-1085 (6mm) ACTION
DPDT On/On 125V RATING
15 amp 250V RATING 277V RATING
10 amp
–
• Fits 7 ⁄ 8 " x 1 3 ⁄ 16 " (22mm x 30mm) opening
• Encased in rubber boot
REF
No. ITEM No.
CONNECTIONS
5
4 tab terminals, 1 ⁄ 4 "
183-1094 (6mm) ACTION
DPST On/Off 125V RATING
16 amp 250V RATING 277V RATING
16 amp
–
• Fits 7 ⁄ 8 " x 1 1 ⁄ 8 " (22mm x 29mm) opening
REF
No. ITEM No.
CONNECTIONS
6
6 tab terminals, 1 ⁄ 4 "
500-1021 (6mm) ACTION
125V RATING
DPDT On/Off/On
16 amp 250V RATING 277V RATING
16 amp
–
• Fits 1" x 3 ⁄ 4 " (25mm x 19mm) opening
REF
No. ITEM No.
CONNECTIONS
7
4 tab terminals, 1 ⁄ 4 "
149-1129 (6mm) ACTION
DPST On/Off 250V RATING 277V RATING
16 amp
–
125V RATING
20 amp
Common Definitions
SP: Single Pole
526
ST: Single Throw
DP: Double Pole
DT: Double Throw
3P: Triple Pole
fmponline.com
MOM: Momentary
