GAS & ELECTRIC High Limits Robertshaw ® Series High Limit Controls ITEM No. 218-1082 202-1140 228-1155 196-1061 146-1004 172-1068 173-1033 194-1084 202-1139 227-1051 218-1057 103-1239 194-1085 175-1061 RSW TYPE LC LC LCC LCCM LCCM LCH LCH LCH LCH LCH LCH LCH LCHM LCHM FIXED TEMP. 450°F 490°F 450°F 450°F 450°F 440°F 440°F 450°F 490°F 450°F 450°F 450°F 440°F 450°F CAPillary LENGTH 36" 30" 60" 36" 36" 30" 24" 36" 30" 24" 54" 36" 36" 30" BULB SIZE 5 ⁄ 16 " x 3 5 ⁄ 8 " 1 ⁄ 4 " x 6 1 ⁄ 2 " 1 ⁄ 4 " x 4 7 ⁄ 8 " 1 ⁄ 4 " x 3 5 ⁄ 8 " 5 ⁄ 16 " x 3 1 ⁄ 8 " 1 ⁄ 4 " x 4 7 ⁄ 8 " 1 ⁄ 4 " x 4 7 ⁄ 8 " 5 ⁄ 16 " x 3 5 ⁄ 8 " 1 ⁄ 4 " x 6 1 ⁄ 2 " 3 ⁄ 16 " x 7 1 ⁄ 4 " 5 ⁄ 16 " x 3 1 ⁄ 8 " 1 ⁄ 4 " x 4 3 ⁄ 4 " 5 ⁄ 16 " x 3 5 ⁄ 8 " 1 ⁄ 4 " x 4 7 ⁄ 8 " STUFFING BOX SIZE 3 ⁄ 8 " NPT None 3 ⁄ 8 " NPT 1 ⁄ 4 " NPT 3 ⁄ 8 " NPT None Panel Nut None None 3 ⁄ 8 " NPT None 3 ⁄ 8 " NPT 3 ⁄ 8 " NPT 1 ⁄ 4 " NPT MOUNT BRKT. #1 #4 #1 #7 #1 #2 #7 #4 #6 #1 #1 #1 #15 #3 RESET Manual Manual Automatic Automatic Automatic Manual Manual Manual Manual Manual Manual Manual Manual Manual Type #1 Type #2 Type #3 ©2013 Franklin Machine Products ©2013 Franklin Machine Products ©2013 Franklin Machine Products Type #4 Type #5 Type #6 ©2013 Franklin Machine Products ©2013 Franklin Machine Products ©2013 Franklin Machine Products Type #7 Type #15 ©2013 Franklin Machine Products ©2013 Franklin Machine Products THERMOSTATS Robertshaw ® D1/D18 Thermostats • Includes dial, bezel, pilot light, and mounting bracket ITEM No. 250-1015 250-1027 194-1017 250-1018 250-1019 172-1064 TEMP. RANGE 60° to 250°F 60° to 250°F 100° to 200°F 100° to 450°F 100° to 550°F 200° to 400°F CAPILLARY LENGTH 42" 84" 48" 60" 60" 36" No. 253-1415 Thermostat dial kit • For thermostat (No. 194-1017) 514 BULB SIZE 3 ⁄ 8 " x 5" 1 ⁄ 4 " x 5 5 ⁄ 32 " 3 ⁄ 8 " x 5 3 ⁄ 16 " 3 ⁄ 16 " x 13" 3 ⁄ 16 " x 13" 3 ⁄ 8 " x 5 3 ⁄ 4 " STUFFING BOX 3 ⁄ 8 " None 3 ⁄ 8 " None None 3 ⁄ 8 " REPLACEMENT DIAL 194-1101 130-1057 253-1415 130-1059 130-1060 130-1061 No. 253-1416 Replacement screw • 8-32 thread fmponline.com No. 250-1027 ©2013 Franklin Machine Products
