GAS & ELECTRIC
burners
Ring Burners
• 1 ⁄ 8 " NPS orifice inlet
• Supplied with air mixer plate and orifices for
natural and LP gas
1
REF
No.
1
2
2
ITEM No.
156-1013
156-1015*
BURNER
DIAMETER
4"
7"
BTU
12,000
28,000
*Unique design allows bottom or side inlet
4
5
7
6
Mushroom Burner
Assembly
No. 156-1014
• 5" diameter
• 20,000 BTU
• 1 ⁄ 8 " NPS orifice inlet
• Supplied with air mixer plate and orifices for
natural and LP gas
No. 184-1015 Replacement air mixer plate
Ring Burners Ring Burner Accessories
REF
No. ITEM No.
3
156-1018
4
156-1019 REF
No.
5
6
7
DESCRIPTION
6" ring burner (20,000 BTU)
8" ring burner (25,000 BTU)
ITEM No.
158-1134
158-1112*
130-1065
DESCRIPTION
Air mixing chamber
1
⁄ 8 " NPT inlet gas valve
Knob
*Gas valve (No. 158-1112) has adjustable orifice for use with natural or LP gas.
12" Ring Burner
Mushroom Burner
Assemblies
No. 156-1020
• Commonly used on wok ranges
• 125,000 BTU
• 3 ⁄ 8 " NPS burner inlet on air mixing chamber
• Supplied with 2 air mixing chambers and plates,
2 orifice nipples, and 2 blank orifices
• Space saving compact design
• 1 ⁄ 8 " NPS orifice inlet
• Supplied with air mixer plate and orifices for
natural and LP gas
ITEM No.
156-1010
156-1011
BURNER DIA.
3"
4"
BTU
5,000
7,000
Note: Requires two 1 1 ⁄ 4 " NPT burner nipples
(not included).
Replacement Parts
No. 158-1132 Air mixer plate
No. 158-1111 #55 orifice
No. 158-1108 #70 orifice
