GAS & ELECTRIC
pilot Accessories
7"
4 3 ⁄ 8 "
14 1 ⁄ 4 "
1 1 ⁄ 2 "
Open Top Pilot Assembly
No. 220-1040
• 3 ⁄ 16 " OD steel tubing
7"
FLEX TUBE KITS
by DORMONT ®
PILOT Burner
• Corrugated
• Kit includes: 1 flexible aluminum pilot tubing,

2 brass compression nuts,

2 brass compression ferrules,

1 brass compression

breakaway ferrule,

Instructions
11"
4 3 ⁄ 8 "
ITEM No.
157-1122
157-1123
157-1124
157-1125
157-1126
157-1127
OD
⁄ 16 "
3
⁄ 16 "
3
⁄ 16 "
1
⁄ 4 "
1
⁄ 4 "
1
⁄ 4 "
3
No. 146-1016
• 3 ⁄ 16 " OD x 10 1 ⁄ 4 " L
LENGTH
18"
24"
30"
18"
24"
30"
Pilot Burner
with Adjustable
Valve
14"
No. 154-1032
• 1 ⁄ 4 " OD x 18" L
• 1 ⁄ 8 " NPT inlet
• Includes pilot valve (No. 154-1033)
Open Top Pilot Assembly
No. 220-1041
• 3 ⁄ 16 " OD steel tubing
7 1 ⁄ 4 "
5 3 ⁄ 16 "
14 1 ⁄ 2 "
Open Top pilot assembly
No. 220-1385
• 3 ⁄ 16 " OD steel tubing
Flexible
PILOT
Assemblies
• 3 ⁄ 16 " OD
• Slotted track fits most
pilot brackets
• Includes pilot head
• Aluminum
No. 154-1043 12" long
No. 154-1044 18" long
No. 154-1045 24" long
pilot tubes
• 36" long
• Steel
• Can be cut to desired length
• Can be easily bent by hand
No. 154-1037 1 ⁄ 8 " OD
No. 154-1040 3 ⁄ 16 " OD
• For use with pilot head (No. 154-1039)
No. 154-1047 1 ⁄ 4 " OD
