Accessories for
Robertshaw ® 700 Series
Combination Valves
Robertshaw ® 700 Series
Bleed Combination Valves
• For use with GS type thermostats
• Natural gas
• 3 ⁄ 4 " NPT inlet and outlet
• Includes two 1 ⁄ 2 " NPT adaptors
• 1 ⁄ 4 " OD tubing outlet for pilot
• 300,000 BTU at 3 ⁄ 4 " NPT ; 100,000 BTU
at 1 ⁄ 2 " NPT
No. 168-1199 Natural gas
• 24 volt
• 1 ⁄ 2 " NPT inlet and outlet
• Robertshaw no. 7000BMSER
No. 168-1075 LP gas
• Millivolt-type
• 3 ⁄ 4 " NPT inlet and outlet
• Thermopile application
• Robertshaw no. 7000BMVR-LP
No. 153-1018 For thermocouple
No. 153-1020 For coaxial thermopile
1. No. 153-1011 Regulator cover plate
• Converts a regulated valve to an
unregulated valve
• For use when installing a separate regulator
2. No. 153-1030 Add-on pressure regulator
• Adjustable for 3 1 ⁄ 2 " WC natural gas
or 11" WC LP gas
Combination Valves
• Millivolt-type
• 1 ⁄ 2 " NPT inlet and 3 ⁄ 4 " NPT outlet
• Includes two 1 ⁄ 2 " NPT plugs and 3 ⁄ 4 " x 1 ⁄ 2 " NPT
reducer bushing
3. No. 169-1056 Add-on pressure regulator
• Converts valve from LP to natural gas
• Includes mounting screws, diaphragm, and
cover plate
No. 228-1206 Natural gas
• Robertshaw no. 7000BMVR
3. No. 153-1033 Add-on pressure regulator
• Converts valve from natural to LP gas
• Includes mounting screws, cover plate,
and diaphragm
Robertshaw ® 700
Series Millivolt
Combination Valves
No. 228-1207 LP gas
• Pressure regulator not included
• For use with pressure regulator (No. 153-1030)
• Robertshaw no. 7000BMVR
• 250 to 750 millivolt operating range
• 3 ⁄ 4 " NPT inlet and outlet
• 1 ⁄ 4 " OD tubing outlet for pilot
• Thermopile application
• 300,000 BTU at 3 ⁄ 4 " NPT; 100,000 BTU at 1 ⁄ 2 " NPT
Robertshaw ® 700
Series Line Voltage
Combination Valves
• 120 volt
• 3 ⁄ 4 " NPT inlet and outlet
• Includes two 1 ⁄ 2 " NPT adaptors
• 1 ⁄ 4 " OD tubing outlet for pilot
• Thermocouple application
• 300,000 BTU at 3 ⁄ 4 " NPT;
100,000 BTU at 1 ⁄ 2 " NPT
No. 153-1016
No. 153-1015
484
Natural gas
LP gas
No. 153-1014 Natural gas
• Coaxial or w ire lead
• Includes two 1 ⁄ 2 " NPT adaptors
No. 153-1013 LP gas
• Wire lead
COMBINATION VALVE
Note: Robertshaw 700 series
LP gas combination valves
do not include gas regulator.
No. 153-1037
• Natural gas
• 120 volt
• ¾" inlet and outlet
• ¼" OD tubing outlet for pilot
• 300000 BTU at ¾" NPT; 100000 at ½" NPT
• Includes two ¾" x ½" reducer
bushings (No. 117-1032)
• Thermopile application
• Robertshaw no. 700-470
