GAS & ELECTRIC
safety Valves
1
Robertshaw ® TS
Replacement Magnet
Head Kits
No. 220-1222
• 1 ⁄ 8 " NPT tubing inlet and outlet for pilot
• 3 ⁄ 8 " NPT inlet/outlet
• 18" capillary length
• 3 ⁄ 16 " button length
• Includes 1 ⁄ 8 " NPT x 3 ⁄ 16 " and 1 ⁄ 8 " NPT x 1 ⁄ 4 "
compression fitting adaptors
No. 153-1007 Inlet and outlet for pilot
No. 153-1008 Outlet for pilot
3
2
• Replaces magnet heads used on many
#11 bodies for TS safety valves
• Kit includes 1 ⁄ 8 " NPT pilot with adaptor
fittings for 3 ⁄ 16 " and 1 ⁄ 4 " OD tubing,
valve gasket, and screws
• Thermocouple application
Robertshaw ® FMDA
Commercial Gas
Safety Valve
Baso ® Safety Valves
Robertshaw ® TS11
Safety Valves
4
baso ® SAFETY VALVEs
• Thermocouple application
1. No. 220-1431 1 ⁄ 4 " NPT inlet and outlet
• 1 ⁄ 8 " NPT pilot inlet and outlet
• Baso no. H15QR3
1. No. 229-1081 ⁄ 8 " NPT inlet and outlet
• 3 ⁄ 16 " OD tubing inlet for pilot
• Baso nos. H15HR2, HI5HR2C, HI5HR2D
3
1. No. 162-1005 ⁄ 8 " NPT inlet and outlet
• 1 ⁄ 4 " OD tubing inlet for pilot
• 1 ⁄ 8 " NPT outlet for pilot
• Baso nos. H15HQ5, HI5HQ5C,
HI5HQ5D
3
• Includes manual shut-off valve
• 1 ⁄ 4 " OD tubing outlet for pilot
• Thermocouple application
• Thermocouple application No. 153-1026 3 ⁄ 8 " NPT inlet and outlet
• Replaces Baso no. H43AB4
• Baso no. H43AA1, H43AB4C, H43AB4D
No. 240-1022 1 ⁄ 4 " NPT inlet and outlet
• 3 ⁄ 16 " tubing pilot inlet and outlet No. 218-1037 1 ⁄ 2 " NPT inlet and outlet
• Baso nos. H43BA2, H43BA2C
No. 220-1376 1 ⁄ 4 " NPT inlet and o utlet
• 1 ⁄ 4 " tubing pilot inlet and outlet
No. 201-1024 3 ⁄ 8 " NPT inlet and outlet
• 1 ⁄ 8 " NPT pilot inlet and outlet
No. 229-1085 3 ⁄ 8 " NPT inlet and outlet
• 3 ⁄ 16 " tubing pilot inlet and outlet
No. 228-1180 7 ⁄ 16 " tubing inlet and outlet
• 1 ⁄ 4 " tubing pilot inlet and outlet
No. 229-1086 1 ⁄ 2 " NPT inlet and outlet
• 1 ⁄ 4 " tubing pilot inlet and outlet
SAFETY Valve
No. 228-1181
• MSC
• 7 ⁄ 16 " inlet and outlet tube
• 24" capillary
• Mercury-filled capillary tube
2. No. 220-1131 3 ⁄ 8 " NPT inlet and outlet
• 1 ⁄ 8 " NPT pilot inlet and outlet
• Baso nos. H15AR3, H15AR3C, H15AR3D
3. No. 147-1019 3 ⁄ 8 " NPT inlet and outlet
• 1 ⁄ 4 " OD tubing inlet and outlet for pilot
• Baso nos. H15HR6, H15HR6C
4. No. 166-1244 1 ⁄ 2 " NPT inlet and outlet
• 1 ⁄ 4 " OD tubing inlet and outlet for pilot
• Baso nos. H15CQ3
Phone: [phone]
SAFETY VALVE
Robertshaw ® #11 Body
for TS Safety Valves
No. 153-1010 3 ⁄ 8 " NPT
No. 153-1009 1 ⁄ 2 " NPT
24-Hour Fax: [phone]
No. 153-1038
• 1 ⁄ 8 " NPT inlet and outlet for pilot
• 3 ⁄ 4 " NPT inlet and outlet
• Includes 2 each: ¾" x ½" (No. 117-1032)
and ¾" x 3 ⁄ 8 " flush bushings
• Thermocouple application
