RESTROOM & JANITORIAL
Grab Bars
stall hardware
by Bobrick ®
1
2
Universal Partition
Base Shoe
©2011 Franklin Machine Products
1. No. 141-1064
End cap
• For 1 1 ⁄ 4 " (32mm) partitions
• 3" (76mm) high
• Chrome-plated, zinc die-cast
• Sold individually (2 required per shoe)
2. No. 141-1065 Spacer plates
• Easily cut to fit most partitions
up to 9" (229mm) wide
• 3" x 10" (76mm x 254mm)
• Stainless steel
• Sold by the pair
GRAB BARS
Grab Bars
• 1 1 ⁄ 2 " (38mm) wall clearance
• Meets FHA, VA, and HEW requirements
• Sanitary safety grip finish
• Stainless steel
1 1 ⁄ 4 "
(32mm)
diameter tubing
No. 141-1179 24"
No. 141-1180 36"
No. 141-1181 42"
1 1 ⁄ 2 "
No.
No.
No.
No.
(38mm)
long
long
(1067mm) long
(610mm)
• 1 1 ⁄ 2 " (38mm) wall clearance
• 1 1 ⁄ 2 " (38mm) diameter tubing
• Meets FHA, VA, and HEW requirements
• Stainless steel
No. 141-2093 24"
No. 141-2094 36"
No. 141-2095 42"
(914mm)
diameter tubing
141-2201
141-1114
141-1115
141-1178
18"
24"
36"
42"
long
long
(914mm) long
(1067mm) long
(457mm)
(610mm)
Partition Base Shoes
• For 1 1 ⁄ 4 " (32mm) thick partitions
• Stainless steel
No.
No.
No.
No.
141-1069
141-1070
141-1071
141-1072
For
For
For
For
3" (76mm) wide partitions
4" (102mm) wide partitions
5" (127mm) wide partitions
6" (152mm) wide partitions
©2011 Franklin Machine Products
W ING I T™ WALL FASTENER
Specially designed for grab bar mounting.
Installs in minutes, ensuring a secure, permanent fit
that maintains its structural integrity.
Partition Anchor Kit
No. 141-1066
• Kit includes all mounting hardware
394
No. 142-1484
• 2 3 ⁄ 4 " (70mm) diameter
• Includes instructions
• Water- and fire-resistant
• Stainless steel
