FMP-COMERSAMX CATALOGO FMP | Page 415

Hardware & Maintenance
dials & knobs
KNOB
CONTROL KNOB
No. 173-1153
• 2" (51mm) diameter
• Fits standard .187" (5mm) diameter D stem
• Flat down in “Off” position
• Black plastic
No. 172-1111
• 1 3 ⁄ 4 " (44mm) diameter
• ¾" (19mm) high
• ¼" (6mm) diameter mounting hole
with set screw
Control Knob
STANDARD-DUTY ELECTRIC
THERMOSTAT DIALS
• Universal 4-way mounting positions
• Fits standard .187" diameter D stem
• Black plastic with chrome face
No. 130-1001
No. 130-1002
No. 130-1003
No. 130-1004
No. 130-1005
No. 130-1007
No. 130-1008
No. 130-1009
No. 130-1083
No. 130-1006
1 to 10
60° to 250°F
100° to 200°F
100° to 450°F
100° to 550°F
200° to 400°F
200° to 550°F
300° to 700°F
Off, Low, 1 to 7, High
Blank
No. 130-1020
• 1 1 ⁄ 2 " (38mm) diameter
• 7 ⁄ 8 " (22mm) high
• 1 ⁄ 4 " (6mm) diameter mounting hole with
set screw
• Universal 4-way mounting positions
• Fits standard .187" diameter D stem
• Black plastic with chrome face
No.
No.
No.
No.
No.
No.
No.
No.
130-1056
130-1057
130-1058
130-1059
130-1060
130-1062
130-1061
130-1063
1 to 10
60 ° to 250 ° F
100 ° to 200 ° F
100 ° to 450 ° F
100 ° to 550 ° F
175 ° to 550 ° F
200 ° to 400 ° F
300 ° to 700 ° F
Infinite
Control Dial
CONTROL DIAL
No. 160-1262
• 2" (51mm) OD
• Fits .187" (5mm) diameter D stem
• Flat down in “Off” position
No. 176-1101
• 1 1 ⁄ 8 " (29mm) diameter
• 9 ⁄ 16 " (14mm) high
• 3 ⁄ 16 " (5mm) square mounting hole with
set screw
No. 130-1027
• 1 1 ⁄ 4 " (32mm) diameter
• 5 ⁄ 8 " (16mm) high
• 1 ⁄ 4 " (6mm) diameter mounting hole with
set screw
Control Knob
Knob
No. 130-1025
• 1 1 ⁄ 8 " (29mm) diameter
• 9 ⁄ 16 " (14mm) high
• 1 ⁄ 4 " (6mm) diameter
mounting hole with
set screw
CONTROL Dial
No. 145-1070
• 2" diameter
• Fits standard .187"
diameter D stem
• Flat up in “Off” position
VALVE KNOB
No. 173-1139
• Fits .25" diameter D stem
• Flat down in “Off” position
• Black plastic
Control Knob
No. 130-1024
• 1 1 ⁄ 2 " (38mm) diameter
• 11 ⁄ 16 " (17mm) high
• 1 ⁄ 4 " (6mm) diameter
mounting hole with brass
insert and set screw
No. 130-1010
• 1 7 ⁄ 8 " (48mm) diameter
• Fits standard .187" (5mm)
diameter D stem
• Flat is down in “Off” position
• Black plastic with chrome face
Phone: [phone]
Control Knob
Control Knob
No. 190-1007
• 2" (51mm) diameter
• Fits .25" (6mm) diameter double D stem
• Heat resistant plastic
Heavy-Duty
Electric Thermostat Dial s
No. 204-1278
• 15 ⁄ 16 " (24mm) OD
• 1 ⁄ 4 " (16mm) ID mounting hole
THERMOSTAT
DIAL
24-Hour Fax: [phone]
Timer KNOB
No. 205-1103
• 1 3 ⁄ 4 " OD
• 3 ⁄ 4 " high
• Fits .187" diameter D stem
• Flat opposite white indicator stripe
357
