Hardware & Maintenance
Bar Stool Swivels
Standard Swivels
Folding Bracket Rigid Bracket
No. 135-1179
• 8 5 ⁄ 8 " D x 3 3 ⁄ 8 " H
• Stainless steel No. 135-1127
• 10 1 ⁄ 2 " D x 4 1 ⁄ 4 " H
(219mm x 86mm)
1"
(25mm)
(267mm x 108mm)
ITEM No.
280-1056 WIDTH
6 3 ⁄ 8 " SCREW CENTERS
4 7 ⁄ 8 " to 5 1 ⁄ 2 "
280-1002 7" 5" to 5 3 ⁄ 4 "
(127mm to 146mm)
(162mm)
(178mm)
(124mm to 140mm)
Heavy-duty Swivel
with Center Return
⁄ 8 "
(22mm)
7
ITEM No.
280-1003
• Stainless steel
WIDTH
7"
(178mm)
SCREW CENTERS
5" to 5 3 ⁄ 4 "
(127mm to 146mm)
3"
2 1 ⁄ 2 "
(76mm)
(64mm)
1 1 ⁄ 4 "
(32mm)
1 1 ⁄ 2 "
(38mm)
Table Hinge
This hinge allows table leaves to be folded
completely up under the table where they
are out of the way.
Snap-in
rubber cushion
No. 135-1020
• Gives extra cushion to glass shelves
Folding Bracket
No. 135-1178
• For shelves up to 10" (254mm) depth
• Bracket folds down neatly when not in use
• 7 1 ⁄ 2 " D x 5 1 ⁄ 4 " H (191mm x 133mm)
• Zinc-plated steel
No. 135-1130
• Leaves can be folded out to add extra
seating capacity
• Heavy gauge plated steel
A
How It Works
A. Hinge locks leaf under
table for storage
B
B. Leaf is quickly folded out
C. Hinge locks leaf in
place to enlarge table
Phone: 800-257-7737
24-Hour Fax: 800-255-9866
C
353
shelving brackets
