Hardware & Maintenance
Leversets & Door Knobs
SIMPLEX ® KEYLESS
PUSHBUTTON DOOR LOCK
by KABA ®
Provides mechanical heavy-duty pushbutton
entry with an easy-to-manage single access
code for all users. No electrical wiring,
electronics, or batteries needed.
No. 134-1199
• Model 1011
• Fits 1 3 ⁄ 8 " to 2 1 ⁄ 4 " (35mm to 57mm) thick doors
• Fits left and right swinging doors
• ½" (13mm) deadlocking solid brass latch
automatically locks when door closes
• 7 3 ⁄ 8 " H x 3 1 ⁄ 8 " W x 3 13 ⁄ 16 " D
(188mm x 79mm x 97mm) lock body
• 1 1 ⁄ 8 " x 2 1 ⁄ 4 " (28mm x 57mm) latch front
• 2 3 ⁄ 4 " (70mm) backset
• For indoor or outdoor use
• Includes hardware and instructions
• Satin chrome-plated
Commercial-Duty
Entry Door Lockset LUDLOW DIGITAL
DOOR LOCK
No. 134-1098
• Adjustable for doors
1 3 ⁄ 8 " to 1 3 ⁄ 4 " (35mm to 44mm) thick
• 2 3 ⁄ 8 " (60mm) backset
• Fits 2 1 ⁄ 8 " (54mm) hole for lock,
7
⁄ 8 " (22mm) for latch
• Stainless steel Protect your facility and manage
employee access.
Lever Locksets
Leverset With
Flair Lever Handles
No. 134-1166
• For use on interior doors from 1 3 ⁄ 8 " to 1 3 ⁄ 4 "
(35mm to 44mm) thick
• 2 3 ⁄ 8 " and 2 3 ⁄ 4 " (60mm and 70mm) backsets
• Brass-plated
350
• Meets ADA and UL requirements
• Inside and outside lever handles work
independently of each other
• Adjustable for doors 1 3 ⁄ 8 " to 1 3 ⁄ 4 "
(35mm to 44mm) thick
• Reversible 1 ⁄ 2 " (13mm) throw dead latch
• Adjustable face plate for flat or
beveled doors
• Satin chrome-plated
Digitally programs multiple security options,
including additions and deletions of
individual employee access. Can program
up to 1000 users with PIN number or Smart
Card. Features master PIN for programming
and temporary PIN numbers for one-time
service or delivery access. Weather-resistant
from – 30° to 150°F (– 35° to 66°C) at 85%
relative humidity.
No. 400-1032
• Model LUDLOW26D
• Fits 1 3 ⁄ 8 " to 2" (35mm to 51mm) thick doors
• For left- or right-swing doors
• For indoor or outdoor use
• 8 1 ⁄ 2 " H x 3 1 ⁄ 2 " W x 3 3 ⁄ 4 " D
(216mm x 89mm x 95) overall
• 2 1 ⁄ 4 " x 1 1 ⁄ 8 " (28mm x 57mm) face plate
• 3 ⁄ 4 " (70mm) backset
• 1 ⁄ 2 " (13mm) deadlock solid brass latch
relocks after 5 seconds and automatically
when door closes
• Features illuminated touch screen for using
in dark, low battery indicator, and
hard-wiring option
• ANSI Grade 1
• Uses 4 AA batteries
(No. 253-1241, included)
• Includes 2 keys, 2 Smart Cards,
instructions, and all necessary
installation hardware
• Satin chrome-plated steel
No. 253-1241 Replacement AA battery
No. 134-1131* Priva cy lockset with push lock
No. 134-1130 Passage lockset without lock
* Includes thru-bolt kit
