FMP-COMERSAMX CATALOGO FMP | Page 374

Hardware & Maintenance
Plate CASTERS
3 1 ⁄ 4 "
(83mm)
2 1 ⁄ 4 "
3"
(76mm)
3 1 ⁄ 8 "
(57mm)
2"
(79mm)
4 1 ⁄ 8 "
(79mm)
4 1 ⁄ 8 "
(105mm)
3"
3 1 ⁄ 8 "
(51mm)
(105mm)
(76mm)
1 3 ⁄ 4 "
2 1 ⁄ 2 "
(44mm)
(64mm)
3 5 ⁄ 8 "
(92mm)
High temperature
MEDIUM-DUTY
SWIVEL PLATE CASTER HIGH TEMPERATURE
MEDIUM-DUTY SWIVEL
CASTER
No. 120-1213
• 4" (102mm) diameter wheel
• 1 1 ⁄ 2 " (38mm) wheel width
• 5" (127mm) load height
• 475°F (246°C) temperature rating
• 1400 lb (635kg) load capacity per set of 4
• Includes brake
• Non-marking brown phenolic wheel and hub No. 120-1212
• 475°F (246°C) maximum temperature rating
• 4" (102mm) wheel diameter
• 1 1 ⁄ 2 " (38mm) wheel width
• 5" (127mm) load height
• 3 ⁄ 8 " (10mm) axle bolt diameter
• 1400 lb (636kg) load capacity per set of 4
• Includes mounting hardware
• Brown phenolic non-marking wheel and hub
3 3 ⁄ 8 "
(86mm)
2 3 ⁄ 4 "
3 5 ⁄ 8 "
(92mm)
3 3 ⁄ 4 "
(70mm)
(95mm)
2 5 ⁄ 8 "
3 3 ⁄ 4 "
(67mm)
4 ⁄ 2 "
(95mm)
1
4 1 ⁄ 2 "
(114mm)
(114mm)
High temperature
MEDIUM-DUTY
SWIVEL PLATE CASTERS
• 4" (102mm) diameter wheel
• 1 1 ⁄ 2 " (38mm) wheel width
• 5 1 ⁄ 4 " (133mm) load height
• 475°F (246°C) temperature rating
• 1400 lb (635kg) load capacity per set of 4
• Non-marking brown phenolic wheel and hub
No. 120-1208 Without brake
No. 120-1209 With brake
316
High temperature
MEDIUM-DUTY
SWIVEL PLATE CASTER HIGH TEMPERATURE
MEDIUM-DUTY
SWIVEL CASTER
No. 120-1211
• 4" (102mm) diameter wheel
• 1 1 ⁄ 2 " (38mm) wheel width
• 5" (127mm) load height
• 475°F (246°C) temperature rating
• 1400 lb (635kg) load capacity per set of 4
• Includes brake
• Non-marking brown phenolic wheel and hub No. 120-1210
• 475°F (246°C) maximum temperature rating
• 4" (102mm) wheel diameter
• 1 1 ⁄ 2 " (38mm) wheel width
• 5" (127mm) load height
• 3 ⁄ 8 " (10mm) axle bolt diameter
• 1400 lb (636kg) load capacity per set of 4
• Includes mounting hardware
• Brown phenolic non-marking wheel and hub
fmponline.com
