Rigid Stem CASTERS
Swivel plate
CASTERS
Rigid Stem Casters
• Polyurethane wheel with plastic hub
Standard-Duty
• 15 ⁄ 16 " wheel width
• 5 ⁄ 16 " axle bolt diameter
• For 1 5 ⁄ 8 " OD tubing
• Plain bearing
No. 120-1074 4" wheel diameter, 4 3 ⁄ 4 " load height
• 600 lb load capacity per set of 4
No. 120-1146 5" wheel diameter, 5 3 ⁄ 4 " load height
• 640 lb load capacity per set of 4
Medium-Duty
2 1 ⁄ 2 "
• 1 1 ⁄ 4 " wheel width
• For 1 5 ⁄ 8 " OD tubing
• 3 ⁄ 8 " axle bolt
• Ball bearing
No. 120-1040 3 ⁄ 2 " wheel diameter, 4 ⁄ 8 " load height
• 900 lb load capacity per set of 4
1
3
Load
Height
No. 120-1145 5" wheel diameter, 6 1 ⁄ 8 " load height
• 1200 lb load capacity per set of 4
SWIVEL PLATE CASTER
Wheel
Diameter
No. 168-1586
• 4" (102mm) diameter wheel
• 1 1 ⁄ 4 " (32mm) wheel width
• 8 1 ⁄ 2 " (216mm) load height
• 1100 lb (499kg) load capacity per
set of 4
• Black polyolefin wheel
©2011 Franklin Machine Products
Rigid plate CASTERS
2 3 ⁄ 8 "
(70mm)
2 3 ⁄ 4 "
(70mm)
1 3 ⁄ 4 "
1 3 ⁄ 4 "
(44mm)
(60mm)
(60mm)
3 5 ⁄ 8 " (92mm)
3 5 ⁄ 8 " (92mm)
©2011 Franklin Machine Products
2
1
2 3 ⁄ 8 "
(44mm)
2 3 ⁄ 8 "
©2011 Franklin Machine Products
Rigid Plate Casters
Load
Height
• Polyurethane wheel with plastic hub
Standard-Duty
• 15 ⁄ 16 " (24mm) wheel width
• 5 ⁄ 16 " axle bolt
• Plain bearing
REF
No.
1
1
1
ITEM No.
120-1022
120-1056**
120-1115
WHEEL
DIAMETER
3" (76mm)
4" (102mm)
5" (127mm)
LOAD
HEIGHT
3 3 ⁄ 4 " (95mm)
4 3 ⁄ 4 " (121mm)
5 3 ⁄ 4 " (146mm) LOAD
CAPACITY*
700 lb (318kg)
880 lb (399kg)
880 lb (399kg)
LOAD
HEIGHT
4 1 ⁄ 2 " (114mm)
6" (152mm) LOAD
CAPACITY*
1000 lb (454kg)
1200 lb (544kg)
medium-Duty
• 1 1 ⁄ 4 " (29mm) wheel width
• 3 ⁄ 8 " axle bolt
• Ball bearing
REF
No. ITEM No.
1
120-1021
2
120-1114
WHEEL
DIAMETER
3 1 ⁄ 2 " (89mm)
5" (127mm)
Wheel
Di ameter
©2011 Franklin Machine Products
A Proud NAFEM
Member For
Over 40 Years.
* Load capacity per set of 4
** 1" (25mm) wheel width
